Oris 50 Linear System Montage Encastré Opal CRI>90
Description
Dans cette section, vous trouverez les références des modules destinés à la création de lignes lumineuses continues pouvant atteindre 50 mètres, avec des raccords invisibles et un système de connexion électrique et mécanique rapide, qui simplifie l'installation et garantit une finition de haute qualité. Il est possible d'inclure des raccords en « L », « T », « X » ou « Y », tout en conservant l'uniformité de la ligne. Il n'est pas possible de combiner différents diffuseurs, projecteurs ou lentilles dans cette configuration. Pour des solutions personnalisées, consultez la section ORIS 50 MODULAR.
Traduit avec DeepL.com (version gratuite)
Caractéristiques techniques
ASSEMBLAGE
Encastrar
DISTRIBUTION DE LA LUMIÈRE
Direct
SOURCE D'ALIMENTATION
220-230V / 50-60 Hz
GARANTIE
5 Années
FINITION
Aluminium Anodisé, Blanc Texturé, Noir Texturé
CONTRÔLE
DALI / Switch Dim, ON/OFF, Tunable White
CARACTÉRISTIQUES DU LED
EFFICACITÉ LUMINEUSE
UP TO 196 lm/W
CRI
CRI>90, Tunable White CRI>90
DURÉE DE VIE
50.000 Heures
STEPS MACADAM
3 STEPS MACADAM
LUMEN MAINTENANCE
L90/B50
RISQUE PHOTOBIOLOGIQUE
RG1
Code produit
Description
104NF.11O9.940.AL
ORIS 50 Linear System encastré opale 27,1W CRI>90 90º IP40 ON/OFF 5Y 1130mm AL 4000K
1130
27.1
Aluminium Anodisé
4000K
ON/OFF
CRI>90
3880
104DA.11O9.930.TB
ORIS 50 Linear System encastré opale 27,1W CRI>90 90º IP40 DALI Push dim 5Y 1130mm TB 3000K
1130
27.1
Noir Texturé
3000K
DALI / Switch Dim
CRI>90
3663
104NF.11O9.930.TB
ORIS 50 Linear System encastré opale 27,1W CRI>90 90º IP40 ON/OFF 5Y 1130mm TB 3000K
1130
27.1
Noir Texturé
3000K
ON/OFF
CRI>90
3663
104DA.11O9.940.TB
ORIS 50 Linear System encastré opale 27,1W CRI>90 90º IP40 DALI Push dim 5Y 1130mm TB 4000K
1130
27.1
Noir Texturé
4000K
DALI / Switch Dim
CRI>90
3880
104NF.11O9.940.TB
ORIS 50 Linear System encastré opale 27,1W CRI>90 90º IP40 ON/OFF 5Y 1130mm TB 4000K
1130
27.1
Noir Texturé
4000K
ON/OFF
CRI>90
3880
104DA.11O9.930.TW
ORIS 50 Linear System encastré opale 27,1W CRI>90 90º IP40 DALI Push dim 5Y 1130mm TW 3000K
1130
27.1
Blanc Texturé
3000K
DALI / Switch Dim
CRI>90
3663
104NF.11O9.930.TW
ORIS 50 Linear System encastré opale 27,1W CRI>90 90º IP40 ON/OFF 5Y 1130mm TW 3000K
1130
27.1
Blanc Texturé
3000K
ON/OFF
CRI>90
3663
104DA.11O9.940.TW
ORIS 50 Linear System encastré opale 27,1W CRI>90 90º IP40 DALI Push dim 5Y 1130mm TW 4000K
1130
27.1
Blanc Texturé
4000K
DALI / Switch Dim
CRI>90
3880
104NF.11O9.940.TW
ORIS 50 Linear System encastré opale 27,1W CRI>90 90º IP40 ON/OFF 5Y 1130mm TW 4000K
1130
27.1
Blanc Texturé
4000K
ON/OFF
CRI>90
3880
104DA.11O9.940.AL
ORIS 50 Linear System encastré opale 27,1W CRI>90 90º IP40 DALI Push dim 5Y 1130mm AL 4000K
1130
27.1
Aluminium Anodisé
4000K
DALI / Switch Dim
CRI>90
3880
104NF.11O9.930.AL
ORIS 50 Linear System encastré opale 27,1W CRI>90 90º IP40 ON/OFF 5Y 1130mm AL 3000K
1130
27.1
Aluminium Anodisé
3000K
ON/OFF
CRI>90
3663
104DA.11O9.930.AL
ORIS 50 Linear System encastré opale 27,1W CRI>90 90º IP40 DALI Push dim 5Y 1130mm AL 3000K
1130
27.1
Aluminium Anodisé
3000K
DALI / Switch Dim
CRI>90
3663
104DA.14O9.930.AL
ORIS 50 Linear System encastré opale 33,9W CRI>90 90º IP40 DALI Push dim 5Y 1410mm AL 3000K
1410
33.9
Aluminium Anodisé
3000K
DALI / Switch Dim
CRI>90
4578
104TU.11O9.92765.AL
ORIS 50 Linear System encastré opale 33,6W CRI>80 90º IP40 Tunable White 5Y 1130mm AL 2700K -> 6500K
1130
33.6
Aluminium Anodisé
2700K - 6500K
Tunable White
Tunable White CRI>90
3091
104DA.14O9.940.AL
ORIS 50 Linear System encastré opale 33,9W CRI>90 90º IP40 DALI Push dim 5Y 1410mm AL 4000K
1410
33.9
Aluminium Anodisé
4000K
DALI / Switch Dim
CRI>90
4850
104NF.14O9.940.AL
ORIS 50 Linear System encastré opale 33,9W CRI>90 90º IP40 ON/OFF 5Y 1410mm AL 4000K
1410
33.9
Aluminium Anodisé
4000K
ON/OFF
CRI>90
4850
104DA.14O9.930.TB
ORIS 50 Linear System encastré opale 33,9W CRI>90 90º IP40 DALI Push dim 5Y 1410mm TB 3000K
1410
33.9
Noir Texturé
3000K
DALI / Switch Dim
CRI>90
4578
104NF.14O9.930.TB
ORIS 50 Linear System encastré opale 33,9W CRI>90 90º IP40 ON/OFF 5Y 1410mm TB 3000K
1410
33.9
Noir Texturé
3000K
ON/OFF
CRI>90
4578
104DA.14O9.940.TB
ORIS 50 Linear System encastré opale 33,9W CRI>90 90º IP40 DALI Push dim 5Y 1410mm TB 4000K
1410
33.9
Noir Texturé
4000K
DALI / Switch Dim
CRI>90
4850
104NF.14O9.940.TB
ORIS 50 Linear System encastré opale 33,9W CRI>90 90º IP40 ON/OFF 5Y 1410mm TB 4000K
1410
33.9
Noir Texturé
4000K
ON/OFF
CRI>90
4850
104DA.14O9.930.TW
ORIS 50 Linear System encastré opale 33,9W CRI>90 90º IP40 DALI Push dim 5Y 1410mm TW 3000K
1410
33.9
Blanc Texturé
3000K
DALI / Switch Dim
CRI>90
4578
104NF.14O9.930.TW
ORIS 50 Linear System encastré opale 33,9W CRI>90 90º IP40 ON/OFF 5Y 1410mm TW 3000K
1410
33.9
Blanc Texturé
3000K
ON/OFF
CRI>90
4578
104DA.14O9.940.TW
ORIS 50 Linear System encastré opale 33,9W CRI>90 90º IP40 DALI Push dim 5Y 1410mm TW 4000K
1410
33.9
Blanc Texturé
4000K
DALI / Switch Dim
CRI>90
4850
104NF.14O9.940.TW
ORIS 50 Linear System encastré opale 33,9W CRI>90 90º IP40 ON/OFF 5Y 1410mm TW 4000K
1410
33.9
Blanc Texturé
4000K
ON/OFF
CRI>90
4850
104TU.11O9.92765.TB
ORIS 50 Linear System encastré opale 33,6W CRI>80 90º IP40 Tunable White 5Y 1130mm TB 2700K -> 6500K
1130
33.6
Noir Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
3091
104TU.11O9.92765.TW
ORIS 50 Linear System encastré opale 33,6W CRI>80 90º IP40 Tunable White 5Y 1130mm TW 2700K -> 6500K
1130
33.6
Blanc Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
3091
104NF.14O9.930.AL
ORIS 50 Linear System encastré opale 33,9W CRI>90 90º IP40 ON/OFF 5Y 1410mm AL 3000K
1410
33.9
Aluminium Anodisé
3000K
ON/OFF
CRI>90
4578
104TU.14O9.92765.AL
ORIS 50 Linear System encastré opale 42W CRI>80 90º IP40 Tunable White 5Y 1410mm AL 2700K -> 6500K
1410
42
Aluminium Anodisé
2700K - 6500K
Tunable White
Tunable White CRI>90
3863
104NF.16O9.930.AL
ORIS 50 Linear System encastré opale 40,7W CRI>90 90º IP40 ON/OFF 5Y 1690mm AL 3000K
1690
40.7
Aluminium Anodisé
3000K
ON/OFF
CRI>90
5494
104DA.16O9.940.AL
ORIS 50 Linear System encastré opale 40,7W CRI>90 90º IP40 DALI Push dim 5Y 1690mm AL 4000K
1690
40.7
Aluminium Anodisé
4000K
DALI / Switch Dim
CRI>90
5820
104NF.16O9.940.AL
ORIS 50 Linear System encastré opale 40,7W CRI>90 90º IP40 ON/OFF 5Y 1690mm AL 4000K
1690
40.7
Aluminium Anodisé
4000K
ON/OFF
CRI>90
5820
104DA.16O9.930.TB
ORIS 50 Linear System encastré opale 40,7W CRI>90 90º IP40 DALI Push dim 5Y 1690mm TB 3000K
1690
40.7
Noir Texturé
3000K
DALI / Switch Dim
CRI>90
5494
104NF.16O9.930.TB
ORIS 50 Linear System encastré opale 40,7W CRI>90 90º IP40 ON/OFF 5Y 1690mm TB 3000K
1690
40.7
Noir Texturé
3000K
ON/OFF
CRI>90
5494
104DA.16O9.940.TB
ORIS 50 Linear System encastré opale 40,7W CRI>90 90º IP40 DALI Push dim 5Y 1690mm TB 4000K
1690
40.7
Noir Texturé
4000K
DALI / Switch Dim
CRI>90
5820
104NF.16O9.940.TB
ORIS 50 Linear System encastré opale 40,7W CRI>90 90º IP40 ON/OFF 5Y 1690mm TB 4000K
1690
40.7
Noir Texturé
4000K
ON/OFF
CRI>90
5820
104DA.16O9.930.TW
ORIS 50 Linear System encastré opale 40,7W CRI>90 90º IP40 DALI Push dim 5Y 1690mm TW 3000K
1690
40.7
Blanc Texturé
3000K
DALI / Switch Dim
CRI>90
5494
104NF.16O9.930.TW
ORIS 50 Linear System encastré opale 40,7W CRI>90 90º IP40 ON/OFF 5Y 1690mm TW 3000K
1690
40.7
Blanc Texturé
3000K
ON/OFF
CRI>90
5494
104DA.16O9.940.TW
ORIS 50 Linear System encastré opale 40,7W CRI>90 90º IP40 DALI Push dim 5Y 1690mm TW 4000K
1690
40.7
Blanc Texturé
4000K
DALI / Switch Dim
CRI>90
5820
104NF.16O9.940.TW
ORIS 50 Linear System encastré opale 40,7W CRI>90 90º IP40 ON/OFF 5Y 1690mm TW 4000K
1690
40.7
Blanc Texturé
4000K
ON/OFF
CRI>90
5820
104TU.16O9.92765.AL
ORIS 50 Linear System encastré opale 50,4W CRI>80 90º IP40 Tunable White 5Y 1690mm AL 2700K -> 6500K
1690
50.4
Aluminium Anodisé
2700K - 6500K
Tunable White
Tunable White CRI>90
4636
104TU.16O9.92765.TB
ORIS 50 Linear System encastré opale 50,4W CRI>80 90º IP40 Tunable White 5Y 1690mm TB 2700K -> 6500K
1690
50.4
Noir Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
4636
104TU.16O9.92765.TW
ORIS 50 Linear System encastré opale 50,4W CRI>80 90º IP40 Tunable White 5Y 1690mm TW 2700K -> 6500K
1690
50.4
Blanc Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
4636
104DA.19O9.930.AL
ORIS 50 Linear System encastré opale 47,5W CRI>90 90º IP40 DALI Push dim 5Y 1970mm AL 3000K
1970
47.5
Aluminium Anodisé
3000K
DALI / Switch Dim
CRI>90
6409
104NF.19O9.930.AL
ORIS 50 Linear System encastré opale 47,5W CRI>90 90º IP40 ON/OFF 5Y 1970mm AL 3000K
1970
47.5
Aluminium Anodisé
3000K
ON/OFF
CRI>90
6409
104DA.19O9.940.AL
ORIS 50 Linear System encastré opale 47,5W CRI>90 90º IP40 DALI Push dim 5Y 1970mm AL 4000K
1970
47.5
Aluminium Anodisé
4000K
DALI / Switch Dim
CRI>90
6791
104NF.19O9.940.AL
ORIS 50 Linear System encastré opale 47,5W CRI>90 90º IP40 ON/OFF 5Y 1970mm AL 4000K
1970
47.5
Aluminium Anodisé
4000K
ON/OFF
CRI>90
6791
104DA.19O9.930.TB
ORIS 50 Linear System encastré opale 47,5W CRI>90 90º IP40 DALI Push dim 5Y 1970mm TB 3000K
1970
47.5
Noir Texturé
3000K
DALI / Switch Dim
CRI>90
6409
104NF.19O9.930.TB
ORIS 50 Linear System encastré opale 47,5W CRI>90 90º IP40 ON/OFF 5Y 1970mm TB 3000K
1970
47.5
Noir Texturé
3000K
ON/OFF
CRI>90
6409
104DA.19O9.940.TB
ORIS 50 Linear System encastré opale 47,5W CRI>90 90º IP40 DALI Push dim 5Y 1970mm TB 4000K
1970
47.5
Noir Texturé
4000K
DALI / Switch Dim
CRI>90
6791
104NF.19O9.940.TB
ORIS 50 Linear System encastré opale 47,5W CRI>90 90º IP40 ON/OFF 5Y 1970mm TB 4000K
1970
47.5
Noir Texturé
4000K
ON/OFF
CRI>90
6791
104DA.19O9.930.TW
ORIS 50 Linear System encastré opale 47,5W CRI>90 90º IP40 DALI Push dim 5Y 1970mm TW 3000K
1970
47.5
Blanc Texturé
3000K
DALI / Switch Dim
CRI>90
6409
104NF.19O9.930.TW
ORIS 50 Linear System encastré opale 47,5W CRI>90 90º IP40 ON/OFF 5Y 1970mm TW 3000K
1970
47.5
Blanc Texturé
3000K
ON/OFF
CRI>90
6409
104DA.19O9.940.TW
ORIS 50 Linear System encastré opale 47,5W CRI>90 90º IP40 DALI Push dim 5Y 1970mm TW 4000K
1970
47.5
Blanc Texturé
4000K
DALI / Switch Dim
CRI>90
6791
104NF.19O9.940.TW
ORIS 50 Linear System encastré opale 47,5W CRI>90 90º IP40 ON/OFF 5Y 1970mm TW 4000K
1970
47.5
Blanc Texturé
4000K
ON/OFF
CRI>90
6791
104TU.19O9.92765.AL
ORIS 50 Linear System encastré opale 58,8W CRI>80 90º IP40 Tunable White 5Y 1970mm AL 2700K -> 6500K
1970
58.8
Aluminium Anodisé
2700K - 6500K
Tunable White
Tunable White CRI>90
5408
104TU.19O9.92765.TB
ORIS 50 Linear System encastré opale 58,8W CRI>80 90º IP40 Tunable White 5Y 1970mm TB 2700K -> 6500K
1970
58.8
Noir Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
5408
104TU.19O9.92765.TW
ORIS 50 Linear System encastré opale 58,8W CRI>80 90º IP40 Tunable White 5Y 1970mm TW 2700K -> 6500K
1970
58.8
Blanc Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
5408
104DA.22O9.930.AL
ORIS 50 Linear System encastré opale 54,2W CRI>90 90º IP40 DALI Push dim 5Y 2250mm AL 3000K
2250
54.2
Aluminium Anodisé
3000K
DALI / Switch Dim
CRI>90
7325
104TU.14O9.92765.TB
ORIS 50 Linear System encastré opale 42W CRI>80 90º IP40 Tunable White 5Y 1410mm TB 2700K -> 6500K
1410
42
Noir Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
3863
104TU.14O9.92765.TW
ORIS 50 Linear System encastré opale 42W CRI>80 90º IP40 Tunable White 5Y 1410mm TW 2700K -> 6500K
1410
42
Blanc Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
3863
104DA.16O9.930.AL
ORIS 50 Linear System encastré opale 40,7W CRI>90 90º IP40 DALI Push dim 5Y 1690mm AL 3000K
1690
40.7
Aluminium Anodisé
3000K
DALI / Switch Dim
CRI>90
5494
104NF.22O9.930.AL
ORIS 50 Linear System encastré opale 54,2W CRI>90 90º IP40 ON/OFF 5Y 2250mm AL 3000K
2250
54.2
Aluminium Anodisé
3000K
ON/OFF
CRI>90
7325
104NF.22O9.930.TB
ORIS 50 Linear System encastré opale 54,2W CRI>90 90º IP40 ON/OFF 5Y 2250mm TB 3000K
2250
54.2
Noir Texturé
3000K
ON/OFF
CRI>90
7325
104DA.22O9.940.TB
ORIS 50 Linear System encastré opale 54,2W CRI>90 90º IP40 DALI Push dim 5Y 2250mm TB 4000K
2250
54.2
Noir Texturé
4000K
DALI / Switch Dim
CRI>90
7761
104NF.22O9.940.TB
ORIS 50 Linear System encastré opale 54,2W CRI>90 90º IP40 ON/OFF 5Y 2250mm TB 4000K
2250
54.2
Noir Texturé
4000K
ON/OFF
CRI>90
7761
104DA.22O9.930.TW
ORIS 50 Linear System encastré opale 54,2W CRI>90 90º IP40 DALI Push dim 5Y 2250mm TW 3000K
2250
54.2
Blanc Texturé
3000K
DALI / Switch Dim
CRI>90
7325
104NF.22O9.930.TW
ORIS 50 Linear System encastré opale 54,2W CRI>90 90º IP40 ON/OFF 5Y 2250mm TW 3000K
2250
54.2
Blanc Texturé
3000K
ON/OFF
CRI>90
7325
104DA.22O9.940.TW
ORIS 50 Linear System encastré opale 54,2W CRI>90 90º IP40 DALI Push dim 5Y 2250mm TW 4000K
2250
54.2
Blanc Texturé
4000K
DALI / Switch Dim
CRI>90
7761
104NF.22O9.940.TW
ORIS 50 Linear System encastré opale 54,2W CRI>90 90º IP40 ON/OFF 5Y 2250mm TW 4000K
2250
54.2
Blanc Texturé
4000K
ON/OFF
CRI>90
7761
104TU.22O9.92765.AL
ORIS 50 Linear System encastré opale 67,2W CRI>80 90º IP40 Tunable White 5Y 2250mm AL 2700K -> 6500K
2250
67.2
Aluminium Anodisé
2700K - 6500K
Tunable White
Tunable White CRI>90
6181
104TU.22O9.92765.TB
ORIS 50 Linear System encastré opale 67,2W CRI>80 90º IP40 Tunable White 5Y 2250mm TB 2700K -> 6500K
2250
67.2
Noir Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
6181
104TU.22O9.92765.TW
ORIS 50 Linear System encastré opale 67,2W CRI>80 90º IP40 Tunable White 5Y 2250mm TW 2700K -> 6500K
2250
67.2
Blanc Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
6181
104DA.25O9.930.AL
ORIS 50 Linear System encastré opale 61W CRI>90 90º IP40 DALI Push dim 5Y 2530mm AL 3000K
2530
61
Aluminium Anodisé
3000K
DALI / Switch Dim
CRI>90
8241
104NF.25O9.930.AL
ORIS 50 Linear System encastré opale 61W CRI>90 90º IP40 ON/OFF 5Y 2530mm AL 3000K
2530
61
Aluminium Anodisé
3000K
ON/OFF
CRI>90
8241
104DA.25O9.940.AL
ORIS 50 Linear System encastré opale 61W CRI>90 90º IP40 DALI Push dim 5Y 2530mm AL 4000K
2530
61
Aluminium Anodisé
4000K
DALI / Switch Dim
CRI>90
8731
104NF.25O9.940.AL
ORIS 50 Linear System encastré opale 61W CRI>90 90º IP40 ON/OFF 5Y 2530mm AL 4000K
2530
61
Aluminium Anodisé
4000K
ON/OFF
CRI>90
8731
104DA.25O9.930.TB
ORIS 50 Linear System encastré opale 61W CRI>90 90º IP40 DALI Push dim 5Y 2530mm TB 3000K
2530
61
Noir Texturé
3000K
DALI / Switch Dim
CRI>90
8241
104NF.25O9.930.TB
ORIS 50 Linear System encastré opale 61W CRI>90 90º IP40 ON/OFF 5Y 2530mm TB 3000K
2530
61
Noir Texturé
3000K
ON/OFF
CRI>90
8241
104DA.25O9.940.TB
ORIS 50 Linear System encastré opale 61W CRI>90 90º IP40 DALI Push dim 5Y 2530mm TB 4000K
2530
61
Noir Texturé
4000K
DALI / Switch Dim
CRI>90
8731
104NF.25O9.940.TB
ORIS 50 Linear System encastré opale 61W CRI>90 90º IP40 ON/OFF 5Y 2530mm TB 4000K
2530
61
Noir Texturé
4000K
ON/OFF
CRI>90
8731
104DA.25O9.930.TW
ORIS 50 Linear System encastré opale 61W CRI>90 90º IP40 DALI Push dim 5Y 2530mm TW 3000K
2530
61
Blanc Texturé
3000K
DALI / Switch Dim
CRI>90
8241
104NF.25O9.930.TW
ORIS 50 Linear System encastré opale 61W CRI>90 90º IP40 ON/OFF 5Y 2530mm TW 3000K
2530
61
Blanc Texturé
3000K
ON/OFF
CRI>90
8241
104DA.25O9.940.TW
ORIS 50 Linear System encastré opale 61W CRI>90 90º IP40 DALI Push dim 5Y 2530mm TW 4000K
2530
61
Blanc Texturé
4000K
DALI / Switch Dim
CRI>90
8731
104NF.25O9.940.TW
ORIS 50 Linear System encastré opale 61W CRI>90 90º IP40 ON/OFF 5Y 2530mm TW 4000K
2530
61
Blanc Texturé
4000K
ON/OFF
CRI>90
8731
104DA.22O9.940.AL
ORIS 50 Linear System encastré opale 54,2W CRI>90 90º IP40 DALI Push dim 5Y 2250mm AL 4000K
2250
54.2
Aluminium Anodisé
4000K
DALI / Switch Dim
CRI>90
7761
104NF.22O9.940.AL
ORIS 50 Linear System encastré opale 54,2W CRI>90 90º IP40 ON/OFF 5Y 2250mm AL 4000K
2250
54.2
Aluminium Anodisé
4000K
ON/OFF
CRI>90
7761
104DA.22O9.930.TB
ORIS 50 Linear System encastré opale 54,2W CRI>90 90º IP40 DALI Push dim 5Y 2250mm TB 3000K
2250
54.2
Noir Texturé
3000K
DALI / Switch Dim
CRI>90
7325
104DA.28O9.930.AL
ORIS 50 Linear System encastré opale 67,8W CRI>90 90º IP40 DALI Push dim 5Y 2810mm AL 3000K
2810
67.8
Aluminium Anodisé
3000K
DALI / Switch Dim
CRI>90
9156
104TU.25O9.92765.AL
ORIS 50 Linear System encastré opale 75,6W CRI>80 90º IP40 Tunable White 5Y 2530mm AL 2700K -> 6500K
2530
75.6
Aluminium Anodisé
2700K - 6500K
Tunable White
Tunable White CRI>90
6954
104DA.28O9.940.AL
ORIS 50 Linear System encastré opale 67,8W CRI>90 90º IP40 DALI Push dim 5Y 2810mm AL 4000K
2810
67.8
Aluminium Anodisé
4000K
DALI / Switch Dim
CRI>90
9701
104TU.25O9.92765.TB
ORIS 50 Linear System encastré opale 75,6W CRI>80 90º IP40 Tunable White 5Y 2530mm TB 2700K -> 6500K
2530
75.6
Noir Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
6954
104DA.28O9.930.TB
ORIS 50 Linear System encastré opale 67,8W CRI>90 90º IP40 DALI Push dim 5Y 2810mm TB 3000K
2810
67.8
Noir Texturé
3000K
DALI / Switch Dim
CRI>90
9156
104TU.25O9.92765.TW
ORIS 50 Linear System encastré opale 75,6W CRI>80 90º IP40 Tunable White 5Y 2530mm TW 2700K -> 6500K
2530
75.6
Blanc Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
6954
104DA.28O9.940.TB
ORIS 50 Linear System encastré opale 67,8W CRI>90 90º IP40 DALI Push dim 5Y 2810mm TB 4000K
2810
67.8
Noir Texturé
4000K
DALI / Switch Dim
CRI>90
9701
104NF.28O9.940.TB
ORIS 50 Linear System encastré opale 67,8W CRI>90 90º IP40 ON/OFF 5Y 2810mm TB 4000K
2810
67.8
Noir Texturé
4000K
ON/OFF
CRI>90
9701
104DA.28O9.930.TW
ORIS 50 Linear System encastré opale 67,8W CRI>90 90º IP40 DALI Push dim 5Y 2810mm TW 3000K
2810
67.8
Blanc Texturé
3000K
DALI / Switch Dim
CRI>90
9156
104NF.28O9.930.TW
ORIS 50 Linear System encastré opale 67,8W CRI>90 90º IP40 ON/OFF 5Y 2810mm TW 3000K
2810
67.8
Blanc Texturé
3000K
ON/OFF
CRI>90
9156
104DA.28O9.940.TW
ORIS 50 Linear System encastré opale 67,8W CRI>90 90º IP40 DALI Push dim 5Y 2810mm TW 4000K
2810
67.8
Blanc Texturé
4000K
DALI / Switch Dim
CRI>90
9701
104NF.28O9.940.TW
ORIS 50 Linear System encastré opale 67,8W CRI>90 90º IP40 ON/OFF 5Y 2810mm TW 4000K
2810
67.8
Blanc Texturé
4000K
ON/OFF
CRI>90
9701
104TU.28O9.92765.AL
ORIS 50 Linear System encastré opale 84W CRI>80 90º IP40 Tunable White 5Y 2810mm AL 2700K -> 6500K
2810
84
Aluminium Anodisé
2700K - 6500K
Tunable White
Tunable White CRI>90
7726
104TU.28O9.92765.TB
ORIS 50 Linear System encastré opale 84W CRI>80 90º IP40 Tunable White 5Y 2810mm TB 2700K -> 6500K
2810
84
Noir Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
7726
104TU.28O9.92765.TW
ORIS 50 Linear System encastré opale 84W CRI>80 90º IP40 Tunable White 5Y 2810mm TW 2700K -> 6500K
2810
84
Blanc Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
7726
104DA.30O9.930.AL
ORIS 50 Linear System encastré opale 74,6W CRI>90 90º IP40 DALI Push dim 5Y 3090mm AL 3000K
3090
74.6
Aluminium Anodisé
3000K
DALI / Switch Dim
CRI>90
10072
104NF.30O9.930.AL
ORIS 50 Linear System encastré opale 74,6W CRI>90 90º IP40 ON/OFF 5Y 3090mm AL 3000K
3090
74.6
Aluminium Anodisé
3000K
ON/OFF
CRI>90
10072
104DA.30O9.940.AL
ORIS 50 Linear System encastré opale 74,6W CRI>90 90º IP40 DALI Push dim 5Y 3090mm AL 4000K
3090
74.6
Aluminium Anodisé
4000K
DALI / Switch Dim
CRI>90
10671
104NF.30O9.940.AL
ORIS 50 Linear System encastré opale 74,6W CRI>90 90º IP40 ON/OFF 5Y 3090mm AL 4000K
3090
74.6
Aluminium Anodisé
4000K
ON/OFF
CRI>90
10671
104DA.30O9.930.TB
ORIS 50 Linear System encastré opale 74,6W CRI>90 90º IP40 DALI Push dim 5Y 3090mm TB 3000K
3090
74.6
Noir Texturé
3000K
DALI / Switch Dim
CRI>90
10072
104NF.30O9.930.TB
ORIS 50 Linear System encastré opale 74,6W CRI>90 90º IP40 ON/OFF 5Y 3090mm TB 3000K
3090
74.6
Noir Texturé
3000K
ON/OFF
CRI>90
10072
104DA.30O9.940.TB
ORIS 50 Linear System encastré opale 74,6W CRI>90 90º IP40 DALI Push dim 5Y 3090mm TB 4000K
3090
74.6
Noir Texturé
4000K
DALI / Switch Dim
CRI>90
10671
104NF.30O9.940.TB
ORIS 50 Linear System encastré opale 74,6W CRI>90 90º IP40 ON/OFF 5Y 3090mm TB 4000K
3090
74.6
Noir Texturé
4000K
ON/OFF
CRI>90
10671
104DA.30O9.930.TW
ORIS 50 Linear System encastré opale 74,6W CRI>90 90º IP40 DALI Push dim 5Y 3090mm TW 3000K
3090
74.6
Blanc Texturé
3000K
DALI / Switch Dim
CRI>90
10072
104NF.30O9.930.TW
ORIS 50 Linear System encastré opale 74,6W CRI>90 90º IP40 ON/OFF 5Y 3090mm TW 3000K
3090
74.6
Blanc Texturé
3000K
ON/OFF
CRI>90
10072
104DA.30O9.940.TW
ORIS 50 Linear System encastré opale 74,6W CRI>90 90º IP40 DALI Push dim 5Y 3090mm TW 4000K
3090
74.6
Blanc Texturé
4000K
DALI / Switch Dim
CRI>90
10671
104NF.30O9.940.TW
ORIS 50 Linear System encastré opale 74,6W CRI>90 90º IP40 ON/OFF 5Y 3090mm TW 4000K
3090
74.6
Blanc Texturé
4000K
ON/OFF
CRI>90
10671
104NF.28O9.940.AL
ORIS 50 Linear System encastré opale 67,8W CRI>90 90º IP40 ON/OFF 5Y 2810mm AL 4000K
2810
67.8
Aluminium Anodisé
4000K
ON/OFF
CRI>90
9701
104NF.28O9.930.TB
ORIS 50 Linear System encastré opale 67,8W CRI>90 90º IP40 ON/OFF 5Y 2810mm TB 3000K
2810
67.8
Noir Texturé
3000K
ON/OFF
CRI>90
9156
104NF.28O9.930.AL
ORIS 50 Linear System encastré opale 67,8W CRI>90 90º IP40 ON/OFF 5Y 2810mm AL 3000K
2810
67.8
Aluminium Anodisé
3000K
ON/OFF
CRI>90
9156
104TU.30O9.92765.TB
ORIS 50 Linear System encastré opale 92,4W CRI>80 90º IP40 Tunable White 5Y 3090mm TB 2700K -> 6500K
3090
92.4
Noir Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
8499
104TU.30O9.92765.TW
ORIS 50 Linear System encastré opale 92,4W CRI>80 90º IP40 Tunable White 5Y 3090mm TW 2700K -> 6500K
3090
92.4
Blanc Texturé
2700K - 6500K
Tunable White
Tunable White CRI>90
8499
104TU.30O9.92765.AL
ORIS 50 Linear System encastré opale 92,4W CRI>80 90º IP40 Tunable White 5Y 3090mm AL 2700K -> 6500K
