Oris 50mm Recessed Mounted Opal

85 90 50

Request a Lighting Project

Description

A space only reveals its true charm with the right lighting. Being aware of this reality, Brilumen presents a LED profiles collection with a 5 Year Warranty, that will help you to create the desired environment. With different wattages, dimensions and mounting types, these profiles can be applied in numerous locations, such as stores, cinemas, museums, galleries, hotels, restaurants, meeting rooms, offices, lounges, etc. With Oris 50mm it’s possible to mount light lines up to 5,05 meters without joining, with or without trims, add emergency kits with 1 or 3 hours of autonomy and choose white, black or aluminium as finishing colour. The LED profiles can also be configured in ON-OFF, Dimming 0-10VDC or with the advanced DALI PUSH DIM. Brilumen has also available the IES and LDT files for DIALux projects, providing technical assistance during the lighting project.

DOWNLOADS

Technical Details

MOUNTING TYPE		Encastrado
LIGHT DISTRIBUTION		Direct
POWER SUPPLY		220-230V / 50-60 Hz
WARRANTY		5 Years
FINISHING		Anodized aluminium, Textured Black, Textured White
CONTROL		1-10V, DALI / Switch Dim, ON/OFF, Tunable White

LED FEATURES
LUMINOUS EFFICIENCY		UP TO 179 lm/W
CRI		CRI>80, CRI>90, Tunable White CRI>80
LIFESPAN		50.000 Hours
STEPS MACADAM		3 Steps MacAdam
LUMEN MAINTENANCE		L90/B50
PHOTOBIOLOGICAL RISK		RG1

SELECT YOUR ITEM CODES

Product code	LENGTH	POWER	FINISHING	COLOR TEMP.	CONTROL TYPE	LED LUMENS	LUMINAIRE LM


1411V.08O9.830.AL	Oris 50mm opal recessed 24W CRI>80 90º IP40 1-10VDC 5Y 850mm AL 3000K
	850	24	Anodized aluminium	3000K	1-10V	3840	2781
1411V.08O9.830.TB	Oris 50mm opal recessed 24W CRI>80 90º IP40 1-10VDC 5Y 850mm TB 3000K
	850	24	Textured Black	3000K	1-10V	3840	2781
1411V.08O9.830.TW	Oris 50mm opal recessed 24W CRI>80 90º IP40 1-10VDC 5Y 850mm TW 3000K
	850	24	Textured White	3000K	1-10V	3840	2781
1411V.08O9.840.AL	Oris 50mm opal recessed 24W CRI>80 90º IP40 1-10VDC 5Y 850mm AL 4000K
	850	24	Anodized aluminium	4000K	1-10V	4040	2926
1411V.08O9.840.TB	Oris 50mm opal recessed 24W CRI>80 90º IP40 1-10VDC 5Y 850mm TB 4000K
	850	24	Textured Black	4000K	1-10V	4040	2926
1411V.08O9.840.TW	Oris 50mm opal recessed 24W CRI>80 90º IP40 1-10VDC 5Y 850mm TW 4000K
	850	24	Textured White	4000K	1-10V	4040	2926
1411V.11O9.830.AL	Oris 50mm opal recessed 32W CRI>80 90º IP40 1-10VDC 5Y 1130mm AL 3000K
	1130	32	Anodized aluminium	3000K	1-10V	5120	3787
1411V.11O9.830.TB	Oris 50mm opal recessed 32W CRI>80 90º IP40 1-10VDC 5Y 1130mm TB 3000K
	1130	32	Textured Black	3000K	1-10V	5120	3787
1411V.11O9.830.TW	Oris 50mm opal recessed 32W CRI>80 90º IP40 1-10VDC 5Y 1130mm TW 3000K
	1130	32	Textured White	3000K	1-10V	5120	3787
1411V.11O9.840.AL	Oris 50mm opal recessed 32W CRI>80 90º IP40 1-10VDC 5Y 1130mm AL 4000K
	1130	32	Anodized aluminium	4000K	1-10V	5400	3994
1411V.11O9.840.TB	Oris 50mm opal recessed 32W CRI>80 90º IP40 1-10VDC 5Y 1130mm TB 4000K
	1130	32	Textured Black	4000K	1-10V	5400	3994
1411V.11O9.840.TW	Oris 50mm opal recessed 32W CRI>80 90º IP40 1-10VDC 5Y 1130mm TW 4000K
	1130	32	Textured White	4000K	1-10V	5400	3994
1411V.14O9.830.AL	Oris 50mm opal recessed 40W CRI>80 90º IP40 1-10VDC 5Y 1410mm AL 3000K
	1410	40	Anodized aluminium	3000K	1-10V	6400	4726
1411V.14O9.830.TB	Oris 50mm opal recessed 40W CRI>80 90º IP40 1-10VDC 5Y 1410mm TB 3000K
	1410	40	Textured Black	3000K	1-10V	6400	4726
1411V.14O9.830.TW	Oris 50mm opal recessed 40W CRI>80 90º IP40 1-10VDC 5Y 1410mm TW 3000K
	1410	40	Textured White	3000K	1-10V	6400	4726
1411V.14O9.840.AL	Oris 50mm opal recessed 40W CRI>80 90º IP40 1-10VDC 5Y 1410mm AL 4000K
	1410	40	Anodized aluminium	4000K	1-10V	6740	4977
1411V.14O9.840.TB	Oris 50mm opal recessed 40W CRI>80 90º IP40 1-10VDC 5Y 1410mm TB 4000K
	1410	40	Textured Black	4000K	1-10V	6740	4977
1411V.14O9.840.TW	Oris 50mm opal recessed 40W CRI>80 90º IP40 1-10VDC 5Y 1410mm TW 4000K
	1410	40	Textured White	4000K	1-10V	6740	4977
1411V.16O9.830.AL	Oris 50mm opal recessed 48W CRI>80 90º IP40 1-10VDC 5Y 1690mm AL 3000K
	1690	48	Anodized aluminium	3000K	1-10V	7680	5631
1411V.16O9.830.TB	Oris 50mm opal recessed 48W CRI>80 90º IP40 1-10VDC 5Y 1690mm TB 3000K
	1690	48	Textured Black	3000K	1-10V	7680	5631
1411V.16O9.830.TW	Oris 50mm opal recessed 48W CRI>80 90º IP40 1-10VDC 5Y 1690mm TW 3000K
	1690	48	Textured White	3000K	1-10V	7680	5631
1411V.16O9.840.AL	Oris 50mm opal recessed 48W CRI>80 90º IP40 1-10VDC 5Y 1690mm AL 4000K
	1690	48	Anodized aluminium	4000K	1-10V	8100	5939
1411V.16O9.840.TB	Oris 50mm opal recessed 48W CRI>80 90º IP40 1-10VDC 5Y 1690mm TB 4000K
	1690	48	Textured Black	4000K	1-10V	8100	5939
1411V.16O9.840.TW	Oris 50mm opal recessed 48W CRI>80 90º IP40 1-10VDC 5Y 1690mm TW 4000K
	1690	48	Textured White	4000K	1-10V	8100	5939
1411V.19O9.830.AL	Oris 50mm opal recessed 56W CRI>80 90º IP40 1-10VDC 5Y 1970mm AL 3000K
	1970	56	Anodized aluminium	3000K	1-10V	8960	6568
1411V.19O9.830.TB	Oris 50mm opal recessed 56W CRI>80 90º IP40 1-10VDC 5Y 1970mm TB 3000K
	1970	56	Textured Black	3000K	1-10V	8960	6568
1411V.19O9.830.TW	Oris 50mm opal recessed 56W CRI>80 90º IP40 1-10VDC 5Y 1970mm TW 3000K
	1970	56	Textured White	3000K	1-10V	8960	6568
1411V.19O9.840.AL	Oris 50mm opal recessed 56W CRI>80 90º IP40 1-10VDC 5Y 1970mm AL 4000K
	1970	56	Anodized aluminium	4000K	1-10V	9440	6920
1411V.19O9.840.TB	Oris 50mm opal recessed 56W CRI>80 90º IP40 1-10VDC 5Y 1970mm TB 4000K
	1970	56	Textured Black	4000K	1-10V	9440	6920
1411V.19O9.840.TW	Oris 50mm opal recessed 56W CRI>80 90º IP40 1-10VDC 5Y 1970mm TW 4000K
	1970	56	Textured White	4000K	1-10V	9440	6920
1411V.22O9.830.AL	Oris 50mm opal recessed 64W CRI>80 90º IP40 1-10VDC 5Y 2250mm AL 3000K
	2250	64	Anodized aluminium	3000K	1-10V	10240	7574
1411V.22O9.830.TB	Oris 50mm opal recessed 64W CRI>80 90º IP40 1-10VDC 5Y 2250mm TB 3000K
	2250	64	Textured Black	3000K	1-10V	10240	7574
1411V.22O9.830.TW	Oris 50mm opal recessed 64W CRI>80 90º IP40 1-10VDC 5Y 2250mm TW 3000K
	2250	64	Textured White	3000K	1-10V	10240	7574
1411V.22O9.840.AL	Oris 50mm opal recessed 64W CRI>80 90º IP40 1-10VDC 5Y 2250mm AL 4000K
	2250	64	Anodized aluminium	4000K	1-10V	10800	7988
1411V.22O9.840.TB	Oris 50mm opal recessed 64W CRI>80 90º IP40 1-10VDC 5Y 2250mm TB 4000K
	2250	64	Textured Black	4000K	1-10V	10800	7988
1411V.22O9.840.TW	Oris 50mm opal recessed 64W CRI>80 90º IP40 1-10VDC 5Y 2250mm TW 4000K
	2250	64	Textured White	4000K	1-10V	10800	7988
1411V.25O9.830.AL	Oris 50mm opal recessed 72W CRI>80 90º IP40 1-10VDC 5Y 2530mm AL 3000K
	2530	72	Anodized aluminium	3000K	1-10V	11520	8513
1411V.25O9.830.TB	Oris 50mm opal recessed 72W CRI>80 90º IP40 1-10VDC 5Y 2530mm TB 3000K
	2530	72	Textured Black	3000K	1-10V	11520	8513
1411V.25O9.830.TW	Oris 50mm opal recessed 72W CRI>80 90º IP40 1-10VDC 5Y 2530mm TW 3000K
	2530	72	Textured White	3000K	1-10V	11520	8513
1411V.25O9.840.AL	Oris 50mm opal recessed 72W CRI>80 90º IP40 1-10VDC 5Y 2530mm AL 4000K
	2530	72	Anodized aluminium	4000K	1-10V	12140	8971
1411V.25O9.840.TB	Oris 50mm opal recessed 72W CRI>80 90º IP40 1-10VDC 5Y 2530mm TB 4000K
	2530	72	Textured Black	4000K	1-10V	12140	8971
1411V.25O9.840.TW	Oris 50mm opal recessed 72W CRI>80 90º IP40 1-10VDC 5Y 2530mm TW 4000K
	2530	72	Textured White	4000K	1-10V	12140	8971
1411V.28O9.830.AL	Oris 50mm opal recessed 80W CRI>80 90º IP40 1-10VDC 5Y 2810mm AL 3000K
	2810	80	Anodized aluminium	3000K	1-10V	12800	9452
1411V.28O9.830.TB	Oris 50mm opal recessed 80W CRI>80 90º IP40 1-10VDC 5Y 2810mm TB 3000K
	2810	80	Textured Black	3000K	1-10V	12800	9452
1411V.28O9.830.TW	Oris 50mm opal recessed 80W CRI>80 90º IP40 1-10VDC 5Y 2810mm TW 3000K
	2810	80	Textured White	3000K	1-10V	12800	9452
1411V.28O9.840.AL	Oris 50mm opal recessed 80W CRI>80 90º IP40 1-10VDC 5Y 2810mm AL 4000K
	2810	80	Anodized aluminium	4000K	1-10V	13480	9954
1411V.28O9.840.TB	Oris 50mm opal recessed 80W CRI>80 90º IP40 1-10VDC 5Y 2810mm TB 4000K
	2810	80	Textured Black	4000K	1-10V	13480	9954
1411V.28O9.840.TW	Oris 50mm opal recessed 80W CRI>80 90º IP40 1-10VDC 5Y 2810mm TW 4000K
	2810	80	Textured White	4000K	1-10V	13480	9954
1411V.30O9.830.AL	Oris 50mm opal recessed 88W CRI>80 90º IP40 1-10VDC 5Y 3090mm AL 3000K
	3090	88	Anodized aluminium	3000K	1-10V	14080	10357
1411V.30O9.830.TB	Oris 50mm opal recessed 88W CRI>80 90º IP40 1-10VDC 5Y 3090mm TB 3000K
	3090	88	Textured Black	3000K	1-10V	14080	10357
1411V.30O9.830.TW	Oris 50mm opal recessed 88W CRI>80 90º IP40 1-10VDC 5Y 3090mm TW 3000K
	3090	88	Textured White	3000K	1-10V	14080	10357
1411V.30O9.840.AL	Oris 50mm opal recessed 88W CRI>80 90º IP40 1-10VDC 5Y 3090mm AL 4000K
	3090	88	Anodized aluminium	4000K	1-10V	14840	10916
1411V.30O9.840.TB	Oris 50mm opal recessed 88W CRI>80 90º IP40 1-10VDC 5Y 3090mm TB 4000K
	3090	88	Textured Black	4000K	1-10V	14840	10916
1411V.30O9.840.TW	Oris 50mm opal recessed 88W CRI>80 90º IP40 1-10VDC 5Y 3090mm TW 4000K
	3090	88	Textured White	4000K	1-10V	14840	10916
1411V.33O9.830.AL	Oris 50mm opal recessed 96W CRI>80 90º IP40 1-10VDC 5Y 3370mm AL 3000K
	3370	96	Anodized aluminium	3000K	1-10V	15360	11262
1411V.33O9.830.TB	Oris 50mm opal recessed 96W CRI>80 90º IP40 1-10VDC 5Y 3370mm TB 3000K
	3370	96	Textured Black	3000K	1-10V	15360	11262
1411V.33O9.830.TW	Oris 50mm opal recessed 96W CRI>80 90º IP40 1-10VDC 5Y 3370mm TW 3000K
	3370	96	Textured White	3000K	1-10V	15360	11262
1411V.33O9.840.AL	Oris 50mm opal recessed 96W CRI>80 90º IP40 1-10VDC 5Y 3370mm AL 4000K
	3370	96	Anodized aluminium	4000K	1-10V	16200	11878
1411V.33O9.840.TB	Oris 50mm opal recessed 96W CRI>80 90º IP40 1-10VDC 5Y 3370mm TB 4000K
	3370	96	Textured Black	4000K	1-10V	16200	11878
1411V.33O9.840.TW	Oris 50mm opal recessed 96W CRI>80 90º IP40 1-10VDC 5Y 3370mm TW 4000K
	3370	96	Textured White	4000K	1-10V	16200	11878
1411V.39O9.830.AL	Oris 50mm opal recessed 112W CRI>80 90º IP40 1-10VDC 5Y 3930mm AL 3000K
	3930	112	Anodized aluminium	3000K	1-10V	17920	13239
1411V.39O9.830.TB	Oris 50mm opal recessed 112W CRI>80 90º IP40 1-10VDC 5Y 3930mm TB 3000K
	3930	112	Textured Black	3000K	1-10V	17920	13239
1411V.39O9.830.TW	Oris 50mm opal recessed 112W CRI>80 90º IP40 1-10VDC 5Y 3930mm TW 3000K
	3930	112	Textured White	3000K	1-10V	17920	13239
1411V.39O9.840.AL	Oris 50mm opal recessed 112W CRI>80 90º IP40 1-10VDC 5Y 3930mm AL 4000K
	3930	112	Anodized aluminium	4000K	1-10V	18880	13948
1411V.39O9.840.TB	Oris 50mm opal recessed 112W CRI>80 90º IP40 1-10VDC 5Y 3930mm TB 4000K
	3930	112	Textured Black	4000K	1-10V	18880	13948
1411V.39O9.840.TW	Oris 50mm opal recessed 112W CRI>80 90º IP40 1-10VDC 5Y 3930mm TW 4000K
	3930	112	Textured White	4000K	1-10V	18880	13948
1411V.44O9.830.AL	Oris 50mm opal recessed 128W CRI>80 90º IP40 1-10VDC 5Y 4490mm AL 3000K
	4490	128	Anodized aluminium	3000K	1-10V	20480	15083
1411V.44O9.830.TB	Oris 50mm opal recessed 128W CRI>80 90º IP40 1-10VDC 5Y 4490mm TB 3000K
	4490	128	Textured Black	3000K	1-10V	20480	15083
1411V.44O9.830.TW	Oris 50mm opal recessed 128W CRI>80 90º IP40 1-10VDC 5Y 4490mm TW 3000K
	4490	128	Textured White	3000K	1-10V	20480	15083
1411V.44O9.840.AL	Oris 50mm opal recessed 128W CRI>80 90º IP40 1-10VDC 5Y 4490mm AL 4000K
	4490	128	Anodized aluminium	4000K	1-10V	21580	15893
1411V.44O9.840.TB	Oris 50mm opal recessed 128W CRI>80 90º IP40 1-10VDC 5Y 4490mm TB 4000K
	4490	128	Textured Black	4000K	1-10V	21580	15893
1411V.44O9.840.TW	Oris 50mm opal recessed 128W CRI>80 90º IP40 1-10VDC 5Y 4490mm TW 4000K
	4490	128	Textured White	4000K	1-10V	21580	15893
1411V.50O9.830.AL	Oris 50mm opal recessed 144W CRI>80 90º IP40 1-10VDC 5Y 5050mm AL 3000K
	5050	144	Anodized aluminium	3000K	1-10V	23040	16893
1411V.50O9.830.TB	Oris 50mm opal recessed 144W CRI>80 90º IP40 1-10VDC 5Y 5050mm TB 3000K
	5050	144	Textured Black	3000K	1-10V	23040	16893
1411V.50O9.830.TW	Oris 50mm opal recessed 144W CRI>80 90º IP40 1-10VDC 5Y 5050mm TW 3000K
	5050	144	Textured White	3000K	1-10V	23040	16893
1411V.50O9.840.AL	Oris 50mm opal recessed 144W CRI>80 90º IP40 1-10VDC 5Y 5050mm AL 4000K
	5050	144	Anodized aluminium	4000K	1-10V	24300	17817
1411V.50O9.840.TB	Oris 50mm opal recessed 144W CRI>80 90º IP40 1-10VDC 5Y 5050mm TB 4000K
	5050	144	Textured Black	4000K	1-10V	24300	17817
1411V.50O9.840.TW	Oris 50mm opal recessed 144W CRI>80 90º IP40 1-10VDC 5Y 5050mm TW 4000K
	5050	144	Textured White	4000K	1-10V	24300	17817
141DA.08O9.830.AL	Oris 50mm opal recessed 24W CRI>80 90º IP40 DALI Push dim 5Y 850mm AL 3000K
	850	24	Anodized aluminium	3000K	DALI / Switch Dim	3840	2781
141DA.08O9.830.TB	Oris 50mm opal recessed 24W CRI>80 90º IP40 DALI Push dim 5Y 850mm TB 3000K
	850	24	Textured Black	3000K	DALI / Switch Dim	3840	2781
141DA.08O9.830.TW	Oris 50mm opal recessed 24W CRI>80 90º IP40 DALI Push dim 5Y 850mm TW 3000K
	850	24	Textured White	3000K	DALI / Switch Dim	3840	2781
141DA.08O9.840.AL	Oris 50mm opal recessed 24W CRI>80 90º IP40 DALI Push dim 5Y 850mm AL 4000K
	850	24	Anodized aluminium	4000K	DALI / Switch Dim	4040	2926
141DA.08O9.840.TB	Oris 50mm opal recessed 24W CRI>80 90º IP40 DALI Push dim 5Y 850mm TB 4000K
	850	24	Textured Black	4000K	DALI / Switch Dim	4040	2926
141DA.08O9.840.TW	Oris 50mm opal recessed 24W CRI>80 90º IP40 DALI Push dim 5Y 850mm TW 4000K
	850	24	Textured White	4000K	DALI / Switch Dim	4040	2926
141DA.11O9.830.AL	Oris 50mm opal recessed 32W CRI>80 90º IP40 DALI Push dim 5Y 1130mm AL 3000K
	1130	32	Anodized aluminium	3000K	DALI / Switch Dim	5120	3787
141DA.11O9.830.TB	Oris 50mm opal recessed 32W CRI>80 90º IP40 DALI Push dim 5Y 1130mm TB 3000K
	1130	32	Textured Black	3000K	DALI / Switch Dim	5120	3787
141DA.11O9.830.TW	Oris 50mm opal recessed 32W CRI>80 90º IP40 DALI Push dim 5Y 1130mm TW 3000K
	1130	32	Textured White	3000K	DALI / Switch Dim	5120	3787
141DA.11O9.840.AL	Oris 50mm opal recessed 32W CRI>80 90º IP40 DALI Push dim 5Y 1130mm AL 4000K
	1130	32	Anodized aluminium	4000K	DALI / Switch Dim	5400	3994
141DA.11O9.840.TB	Oris 50mm opal recessed 32W CRI>80 90º IP40 DALI Push dim 5Y 1130mm TB 4000K
	1130	32	Textured Black	4000K	DALI / Switch Dim	5400	3994
141DA.11O9.840.TW	Oris 50mm opal recessed 32W CRI>80 90º IP40 DALI Push dim 5Y 1130mm TW 4000K
	1130	32	Textured White	4000K	DALI / Switch Dim	5400	3994
141DA.14O9.830.AL	Oris 50mm opal recessed 40W CRI>80 90º IP40 DALI Push dim 5Y 1410mm AL 3000K
	1410	40	Anodized aluminium	3000K	DALI / Switch Dim	6400	4726
141DA.14O9.830.TB	Oris 50mm opal recessed 40W CRI>80 90º IP40 DALI Push dim 5Y 1410mm TB 3000K
	1410	40	Textured Black	3000K	DALI / Switch Dim	6400	4726
141DA.14O9.830.TW	Oris 50mm opal recessed 40W CRI>80 90º IP40 DALI Push dim 5Y 1410mm TW 3000K
	1410	40	Textured White	3000K	DALI / Switch Dim	6400	4726
141DA.14O9.840.AL	Oris 50mm opal recessed 40W CRI>80 90º IP40 DALI Push dim 5Y 1410mm AL 4000K
	1410	40	Anodized aluminium	4000K	DALI / Switch Dim	6740	4977
141DA.14O9.840.TB	Oris 50mm opal recessed 40W CRI>80 90º IP40 DALI Push dim 5Y 1410mm TB 4000K
	1410	40	Textured Black	4000K	DALI / Switch Dim	6740	4977
141DA.14O9.840.TW	Oris 50mm opal recessed 40W CRI>80 90º IP40 DALI Push dim 5Y 1410mm TW 4000K
	1410	40	Textured White	4000K	DALI / Switch Dim	6740	4977
141DA.16O9.830.AL	Oris 50mm opal recessed 48W CRI>80 90º IP40 DALI Push dim 5Y 1690mm AL 3000K
	1690	48	Anodized aluminium	3000K	DALI / Switch Dim	7680	5631
141DA.16O9.830.TB	Oris 50mm opal recessed 48W CRI>80 90º IP40 DALI Push dim 5Y 1690mm TB 3000K
	1690	48	Textured Black	3000K	DALI / Switch Dim	7680	5631
141DA.16O9.830.TW	Oris 50mm opal recessed 48W CRI>80 90º IP40 DALI Push dim 5Y 1690mm TW 3000K
	1690	48	Textured White	3000K	DALI / Switch Dim	7680	5631
141DA.16O9.840.AL	Oris 50mm opal recessed 48W CRI>80 90º IP40 DALI Push dim 5Y 1690mm AL 4000K
	1690	48	Anodized aluminium	4000K	DALI / Switch Dim	8100	5939
141DA.16O9.840.TB	Oris 50mm opal recessed 48W CRI>80 90º IP40 DALI Push dim 5Y 1690mm TB 4000K
	1690	48	Textured Black	4000K	DALI / Switch Dim	8100	5939
141DA.16O9.840.TW	Oris 50mm opal recessed 48W CRI>80 90º IP40 DALI Push dim 5Y 1690mm TW 4000K
	1690	48	Textured White	4000K	DALI / Switch Dim	8100	5939
141DA.19O9.830.AL	Oris 50mm opal recessed 56W CRI>80 90º IP40 DALI Push dim 5Y 1970mm AL 3000K
	1970	56	Anodized aluminium	3000K	DALI / Switch Dim	8960	6568
141DA.19O9.830.TB	Oris 50mm opal recessed 56W CRI>80 90º IP40 DALI Push dim 5Y 1970mm TB 3000K
	1970	56	Textured Black	3000K	DALI / Switch Dim	8960	6568
141DA.19O9.830.TW	Oris 50mm opal recessed 56W CRI>80 90º IP40 DALI Push dim 5Y 1970mm TW 3000K
	1970	56	Textured White	3000K	DALI / Switch Dim	8960	6568
141DA.19O9.840.AL	Oris 50mm opal recessed 56W CRI>80 90º IP40 DALI Push dim 5Y 1970mm AL 4000K
	1970	56	Anodized aluminium	4000K	DALI / Switch Dim	9440	6920
141DA.19O9.840.TB	Oris 50mm opal recessed 56W CRI>80 90º IP40 DALI Push dim 5Y 1970mm TB 4000K
	1970	56	Textured Black	4000K	DALI / Switch Dim	9440	6920
141DA.19O9.840.TW	Oris 50mm opal recessed 56W CRI>80 90º IP40 DALI Push dim 5Y 1970mm TW 4000K
	1970	56	Textured White	4000K	DALI / Switch Dim	9440	6920
141DA.22O9.830.AL	Oris 50mm opal recessed 64W CRI>80 90º IP40 DALI Push dim 5Y 2250mm AL 3000K
	2250	64	Anodized aluminium	3000K	DALI / Switch Dim	10240	7574
141DA.22O9.830.TB	Oris 50mm opal recessed 64W CRI>80 90º IP40 DALI Push dim 5Y 2250mm TB 3000K
	2250	64	Textured Black	3000K	DALI / Switch Dim	10240	7574
141DA.22O9.830.TW	Oris 50mm opal recessed 64W CRI>80 90º IP40 DALI Push dim 5Y 2250mm TW 3000K
	2250	64	Textured White	3000K	DALI / Switch Dim	10240	7574
141DA.22O9.840.AL	Oris 50mm opal recessed 64W CRI>80 90º IP40 DALI Push dim 5Y 2250mm AL 4000K
	2250	64	Anodized aluminium	4000K	DALI / Switch Dim	10800	7988
141DA.22O9.840.TB	Oris 50mm opal recessed 64W CRI>80 90º IP40 DALI Push dim 5Y 2250mm TB 4000K
	2250	64	Textured Black	4000K	DALI / Switch Dim	10800	7988
141DA.22O9.840.TW	Oris 50mm opal recessed 64W CRI>80 90º IP40 DALI Push dim 5Y 2250mm TW 4000K
	2250	64	Textured White	4000K	DALI / Switch Dim	10800	7988
141DA.25O9.830.AL	Oris 50mm opal recessed 72W CRI>80 90º IP40 DALI Push dim 5Y 2530mm AL 3000K
	2530	72	Anodized aluminium	3000K	DALI / Switch Dim	11520	8513
141DA.25O9.830.TB	Oris 50mm opal recessed 72W CRI>80 90º IP40 DALI Push dim 5Y 2530mm TB 3000K
	2530	72	Textured Black	3000K	DALI / Switch Dim	11520	8513
141DA.25O9.830.TW	Oris 50mm opal recessed 72W CRI>80 90º IP40 DALI Push dim 5Y 2530mm TW 3000K
	2530	72	Textured White	3000K	DALI / Switch Dim	11520	8513
141DA.25O9.840.AL	Oris 50mm opal recessed 72W CRI>80 90º IP40 DALI Push dim 5Y 2530mm AL 4000K
	2530	72	Anodized aluminium	4000K	DALI / Switch Dim	12140	8971
141DA.25O9.840.TB	Oris 50mm opal recessed 72W CRI>80 90º IP40 DALI Push dim 5Y 2530mm TB 4000K
	2530	72	Textured Black	4000K	DALI / Switch Dim	12140	8971
141DA.25O9.840.TW	Oris 50mm opal recessed 72W CRI>80 90º IP40 DALI Push dim 5Y 2530mm TW 4000K
	2530	72	Textured White	4000K	DALI / Switch Dim	12140	8971
141DA.28O9.830.AL	Oris 50mm opal recessed 80W CRI>80 90º IP40 DALI Push dim 5Y 2810mm AL 3000K
	2810	80	Anodized aluminium	3000K	DALI / Switch Dim	12800	9452
141DA.28O9.830.TB	Oris 50mm opal recessed 80W CRI>80 90º IP40 DALI Push dim 5Y 2810mm TB 3000K
	2810	80	Textured Black	3000K	DALI / Switch Dim	12800	9452
141DA.28O9.830.TW	Oris 50mm opal recessed 80W CRI>80 90º IP40 DALI Push dim 5Y 2810mm TW 3000K
	2810	80	Textured White	3000K	DALI / Switch Dim	12800	9452
141DA.28O9.840.AL	Oris 50mm opal recessed 80W CRI>80 90º IP40 DALI Push dim 5Y 2810mm AL 4000K
	2810	80	Anodized aluminium	4000K	DALI / Switch Dim	13480	9954
141DA.28O9.840.TB	Oris 50mm opal recessed 80W CRI>80 90º IP40 DALI Push dim 5Y 2810mm TB 4000K
	2810	80	Textured Black	4000K	DALI / Switch Dim	13480	9954
141DA.28O9.840.TW	Oris 50mm opal recessed 80W CRI>80 90º IP40 DALI Push dim 5Y 2810mm TW 4000K
	2810	80	Textured White	4000K	DALI / Switch Dim	13480	9954
141DA.30O9.830.AL	Oris 50mm opal recessed 88W CRI>80 90º IP40 DALI Push dim 5Y 3090mm AL 3000K
	3090	88	Anodized aluminium	3000K	DALI / Switch Dim	14080	10357
141DA.30O9.830.TB	Oris 50mm opal recessed 88W CRI>80 90º IP40 DALI Push dim 5Y 3090mm TB 3000K
	3090	88	Textured Black	3000K	DALI / Switch Dim	14080	10357
141DA.30O9.830.TW	Oris 50mm opal recessed 88W CRI>80 90º IP40 DALI Push dim 5Y 3090mm TW 3000K
	3090	88	Textured White	3000K	DALI / Switch Dim	14080	10357
141DA.30O9.840.AL	Oris 50mm opal recessed 88W CRI>80 90º IP40 DALI Push dim 5Y 3090mm AL 4000K
	3090	88	Anodized aluminium	4000K	DALI / Switch Dim	14840	10916
141DA.30O9.840.TB	Oris 50mm opal recessed 88W CRI>80 90º IP40 DALI Push dim 5Y 3090mm TB 4000K
	3090	88	Textured Black	4000K	DALI / Switch Dim	14840	10916
141DA.30O9.840.TW	Oris 50mm opal recessed 88W CRI>80 90º IP40 DALI Push dim 5Y 3090mm TW 4000K
	3090	88	Textured White	4000K	DALI / Switch Dim	14840	10916
141DA.33O9.830.AL	Oris 50mm opal recessed 96W CRI>80 90º IP40 DALI Push dim 5Y 3370mm AL 3000K
	3370	96	Anodized aluminium	3000K	DALI / Switch Dim	15360	11262
141DA.33O9.830.TB	Oris 50mm opal recessed 96W CRI>80 90º IP40 DALI Push dim 5Y 3370mm TB 3000K
	3370	96	Textured Black	3000K	DALI / Switch Dim	15360	11262
141DA.33O9.830.TW	Oris 50mm opal recessed 96W CRI>80 90º IP40 DALI Push dim 5Y 3370mm TW 3000K
	3370	96	Textured White	3000K	DALI / Switch Dim	15360	11262
141DA.33O9.840.AL	Oris 50mm opal recessed 96W CRI>80 90º IP40 DALI Push dim 5Y 3370mm AL 4000K
	3370	96	Anodized aluminium	4000K	DALI / Switch Dim	16200	11878
141DA.33O9.840.TB	Oris 50mm opal recessed 96W CRI>80 90º IP40 DALI Push dim 5Y 3370mm TB 4000K
	3370	96	Textured Black	4000K	DALI / Switch Dim	16200	11878
141DA.33O9.840.TW	Oris 50mm opal recessed 96W CRI>80 90º IP40 DALI Push dim 5Y 3370mm TW 4000K
	3370	96	Textured White	4000K	DALI / Switch Dim	16200	11878
141DA.39O9.830.AL	Oris 50mm opal recessed 112W CRI>80 90º IP40 DALI Push dim 5Y 3930mm AL 3000K
	3930	112	Anodized aluminium	3000K	DALI / Switch Dim	17920	13239
141DA.39O9.830.TB	Oris 50mm opal recessed 112W CRI>80 90º IP40 DALI Push dim 5Y 3930mm TB 3000K
	3930	112	Textured Black	3000K	DALI / Switch Dim	17920	13239
141DA.39O9.830.TW	Oris 50mm opal recessed 112W CRI>80 90º IP40 DALI Push dim 5Y 3930mm TW 3000K
	3930	112	Textured White	3000K	DALI / Switch Dim	17920	13239
141DA.39O9.840.AL	Oris 50mm opal recessed 112W CRI>80 90º IP40 DALI Push dim 5Y 3930mm AL 4000K
	3930	112	Anodized aluminium	4000K	DALI / Switch Dim	18880	13948
141DA.39O9.840.TB	Oris 50mm opal recessed 112W CRI>80 90º IP40 DALI Push dim 5Y 3930mm TB 4000K
	3930	112	Textured Black	4000K	DALI / Switch Dim	18880	13948
141DA.39O9.840.TW	Oris 50mm opal recessed 112W CRI>80 90º IP40 DALI Push dim 5Y 3930mm TW 4000K
	3930	112	Textured White	4000K	DALI / Switch Dim	18880	13948
141DA.44O9.830.AL	Oris 50mm opal recessed 128W CRI>80 90º IP40 DALI Push dim 5Y 4490mm AL 3000K
	4490	128	Anodized aluminium	3000K	DALI / Switch Dim	20480	15083
141DA.44O9.830.TB	Oris 50mm opal recessed 128W CRI>80 90º IP40 DALI Push dim 5Y 4490mm TB 3000K
	4490	128	Textured Black	3000K	DALI / Switch Dim	20480	15083
141DA.44O9.830.TW	Oris 50mm opal recessed 128W CRI>80 90º IP40 DALI Push dim 5Y 4490mm TW 3000K
	4490	128	Textured White	3000K	DALI / Switch Dim	20480	15083
141DA.44O9.840.AL	Oris 50mm opal recessed 128W CRI>80 90º IP40 DALI Push dim 5Y 4490mm AL 4000K
	4490	128	Anodized aluminium	4000K	DALI / Switch Dim	21580	15893
141DA.44O9.840.TB	Oris 50mm opal recessed 128W CRI>80 90º IP40 DALI Push dim 5Y 4490mm TB 4000K
	4490	128	Textured Black	4000K	DALI / Switch Dim	21580	15893
141DA.44O9.840.TW	Oris 50mm opal recessed 128W CRI>80 90º IP40 DALI Push dim 5Y 4490mm TW 4000K
	4490	128	Textured White	4000K	DALI / Switch Dim	21580	15893
141DA.50O9.830.AL	Oris 50mm opal recessed 144W CRI>80 90º IP40 DALI Push dim 5Y 5050mm AL 3000K
	5050	144	Anodized aluminium	3000K	DALI / Switch Dim	23040	16893
141DA.50O9.830.TB	Oris 50mm opal recessed 144W CRI>80 90º IP40 DALI Push dim 5Y 5050mm TB 3000K
	5050	144	Textured Black	3000K	DALI / Switch Dim	23040	16893
141DA.50O9.830.TW	Oris 50mm opal recessed 144W CRI>80 90º IP40 DALI Push dim 5Y 5050mm TW 3000K
	5050	144	Textured White	3000K	DALI / Switch Dim	23040	16893
141DA.50O9.840.AL	Oris 50mm opal recessed 144W CRI>80 90º IP40 DALI Push dim 5Y 5050mm AL 4000K
	5050	144	Anodized aluminium	4000K	DALI / Switch Dim	24300	17817
141DA.50O9.840.TB	Oris 50mm opal recessed 144W CRI>80 90º IP40 DALI Push dim 5Y 5050mm TB 4000K
	5050	144	Textured Black	4000K	DALI / Switch Dim	24300	17817
141DA.50O9.840.TW	Oris 50mm opal recessed 144W CRI>80 90º IP40 DALI Push dim 5Y 5050mm TW 4000K
	5050	144	Textured White	4000K	DALI / Switch Dim	24300	17817
141NF.08O9.830.AL	Oris 50mm opal recessed 24W CRI>80 90º IP40 ON/OFF 5Y 850mm AL 3000K
	850	24	Anodized aluminium	3000K	ON/OFF	3840	2781
141NF.08O9.830.TB	Oris 50mm opal recessed 24W CRI>80 90º IP40 ON/OFF 5Y 850mm TB 3000K
	850	24	Textured Black	3000K	ON/OFF	3840	2781
141NF.08O9.830.TW	Oris 50mm opal recessed 24W CRI>80 90º IP40 ON/OFF 5Y 850mm TW 3000K
	850	24	Textured White	3000K	ON/OFF	3840	2781
141NF.08O9.840.AL	Oris 50mm opal recessed 24W CRI>80 90º IP40 ON/OFF 5Y 850mm AL 4000K
	850	24	Anodized aluminium	4000K	ON/OFF	4040	2926
141NF.08O9.840.TB	Oris 50mm opal recessed 24W CRI>80 90º IP40 ON/OFF 5Y 850mm TB 4000K
	850	24	Textured Black	4000K	ON/OFF	4040	2926
141NF.08O9.840.TW	Oris 50mm opal recessed 24W CRI>80 90º IP40 ON/OFF 5Y 850mm TW 4000K
	850	24	Textured White	4000K	ON/OFF	4040	2926
141NF.11O9.830.AL	Oris 50mm opal recessed 32W CRI>80 90º IP40 ON/OFF 5Y 1130mm AL 3000K
	1130	32	Anodized aluminium	3000K	ON/OFF	5120	3787
141NF.11O9.830.TB	Oris 50mm opal recessed 32W CRI>80 90º IP40 ON/OFF 5Y 1130mm TB 3000K
	1130	32	Textured Black	3000K	ON/OFF	5120	3787
141NF.11O9.830.TW	Oris 50mm opal recessed 32W CRI>80 90º IP40 ON/OFF 5Y 1130mm TW 3000K
	1130	32	Textured White	3000K	ON/OFF	5120	3787
141NF.11O9.840.AL	Oris 50mm opal recessed 32W CRI>80 90º IP40 ON/OFF 5Y 1130mm AL 4000K
	1130	32	Anodized aluminium	4000K	ON/OFF	5400	3994
141NF.11O9.840.TB	Oris 50mm opal recessed 32W CRI>80 90º IP40 ON/OFF 5Y 1130mm TB 4000K
	1130	32	Textured Black	4000K	ON/OFF	5400	3994
141NF.11O9.840.TW	Oris 50mm opal recessed 32W CRI>80 90º IP40 ON/OFF 5Y 1130mm TW 4000K
	1130	32	Textured White	4000K	ON/OFF	5400	3994
141NF.14O9.830.AL	Oris 50mm opal recessed 40W CRI>80 90º IP40 ON/OFF 5Y 1410mm AL 3000K
	1410	40	Anodized aluminium	3000K	ON/OFF	6400	4726
141NF.14O9.830.TB	Oris 50mm opal recessed 40W CRI>80 90º IP40 ON/OFF 5Y 1410mm TB 3000K
	1410	40	Textured Black	3000K	ON/OFF	6400	4726
141NF.14O9.830.TW	Oris 50mm opal recessed 40W CRI>80 90º IP40 ON/OFF 5Y 1410mm TW 3000K
	1410	40	Textured White	3000K	ON/OFF	6400	4726
141NF.14O9.840.AL	Oris 50mm opal recessed 40W CRI>80 90º IP40 ON/OFF 5Y 1410mm AL 4000K
	1410	40	Anodized aluminium	4000K	ON/OFF	6740	4977
141NF.14O9.840.TB	Oris 50mm opal recessed 40W CRI>80 90º IP40 ON/OFF 5Y 1410mm TB 4000K
	1410	40	Textured Black	4000K	ON/OFF	6740	4977
141NF.14O9.840.TW	Oris 50mm opal recessed 40W CRI>80 90º IP40 ON/OFF 5Y 1410mm TW 4000K
	1410	40	Textured White	4000K	ON/OFF	6740	4977
141NF.16O9.830.AL	Oris 50mm opal recessed 48W CRI>80 90º IP40 ON/OFF 5Y 1690mm AL 3000K
	1690	48	Anodized aluminium	3000K	ON/OFF	7680	5631
141NF.16O9.830.TB	Oris 50mm opal recessed 48W CRI>80 90º IP40 ON/OFF 5Y 1690mm TB 3000K
	1690	48	Textured Black	3000K	ON/OFF	7680	5631
141NF.16O9.830.TW	Oris 50mm opal recessed 48W CRI>80 90º IP40 ON/OFF 5Y 1690mm TW 3000K
	1690	48	Textured White	3000K	ON/OFF	7680	5631
141NF.16O9.840.AL	Oris 50mm opal recessed 48W CRI>80 90º IP40 ON/OFF 5Y 1690mm AL 4000K
	1690	48	Anodized aluminium	4000K	ON/OFF	8100	5939
141NF.16O9.840.TB	Oris 50mm opal recessed 48W CRI>80 90º IP40 ON/OFF 5Y 1690mm TB 4000K
	1690	48	Textured Black	4000K	ON/OFF	8100	5939
141NF.16O9.840.TW	Oris 50mm opal recessed 48W CRI>80 90º IP40 ON/OFF 5Y 1690mm TW 4000K
	1690	48	Textured White	4000K	ON/OFF	8100	5939
141NF.19O9.830.AL	Oris 50mm opal recessed 56W CRI>80 90º IP40 ON/OFF 5Y 1970mm AL 3000K
	1970	56	Anodized aluminium	3000K	ON/OFF	8960	6568
141NF.19O9.830.TB	Oris 50mm opal recessed 56W CRI>80 90º IP40 ON/OFF 5Y 1970mm TB 3000K
	1970	56	Textured Black	3000K	ON/OFF	8960	6568
141NF.19O9.830.TW	Oris 50mm opal recessed 56W CRI>80 90º IP40 ON/OFF 5Y 1970mm TW 3000K
	1970	56	Textured White	3000K	ON/OFF	8960	6568
141NF.19O9.840.AL	Oris 50mm opal recessed 56W CRI>80 90º IP40 ON/OFF 5Y 1970mm AL 4000K
	1970	56	Anodized aluminium	4000K	ON/OFF	9440	6920
141NF.19O9.840.TB	Oris 50mm opal recessed 56W CRI>80 90º IP40 ON/OFF 5Y 1970mm TB 4000K
	1970	56	Textured Black	4000K	ON/OFF	9440	6920
141NF.19O9.840.TW	Oris 50mm opal recessed 56W CRI>80 90º IP40 ON/OFF 5Y 1970mm TW 4000K
	1970	56	Textured White	4000K	ON/OFF	9440	6920
141NF.22O9.830.AL	Oris 50mm opal recessed 64W CRI>80 90º IP40 ON/OFF 5Y 2250mm AL 3000K
	2250	64	Anodized aluminium	3000K	ON/OFF	10240	7574
141NF.22O9.830.TB	Oris 50mm opal recessed 64W CRI>80 90º IP40 ON/OFF 5Y 2250mm TB 3000K
	2250	64	Textured Black	3000K	ON/OFF	10240	7574
141NF.22O9.830.TW	Oris 50mm opal recessed 64W CRI>80 90º IP40 ON/OFF 5Y 2250mm TW 3000K
	2250	64	Textured White	3000K	ON/OFF	10240	7574
141NF.22O9.840.AL	Oris 50mm opal recessed 64W CRI>80 90º IP40 ON/OFF 5Y 2250mm AL 4000K
	2250	64	Anodized aluminium	4000K	ON/OFF	10800	7988
141NF.22O9.840.TB	Oris 50mm opal recessed 64W CRI>80 90º IP40 ON/OFF 5Y 2250mm TB 4000K
	2250	64	Textured Black	4000K	ON/OFF	10800	7988
141NF.22O9.840.TW	Oris 50mm opal recessed 64W CRI>80 90º IP40 ON/OFF 5Y 2250mm TW 4000K
	2250	64	Textured White	4000K	ON/OFF	10800	7988
141NF.25O9.830.AL	Oris 50mm opal recessed 72W CRI>80 90º IP40 ON/OFF 5Y 2530mm AL 3000K
	2530	72	Anodized aluminium	3000K	ON/OFF	11520	8513
141NF.25O9.830.TB	Oris 50mm opal recessed 72W CRI>80 90º IP40 ON/OFF 5Y 2530mm TB 3000K
	2530	72	Textured Black	3000K	ON/OFF	11520	8513
141NF.25O9.830.TW	Oris 50mm opal recessed 72W CRI>80 90º IP40 ON/OFF 5Y 2530mm TW 3000K
	2530	72	Textured White	3000K	ON/OFF	11520	8513
141NF.25O9.840.AL	Oris 50mm opal recessed 72W CRI>80 90º IP40 ON/OFF 5Y 2530mm AL 4000K
	2530	72	Anodized aluminium	4000K	ON/OFF	12140	8971
141NF.25O9.840.TB	Oris 50mm opal recessed 72W CRI>80 90º IP40 ON/OFF 5Y 2530mm TB 4000K
	2530	72	Textured Black	4000K	ON/OFF	12140	8971
141NF.25O9.840.TW	Oris 50mm opal recessed 72W CRI>80 90º IP40 ON/OFF 5Y 2530mm TW 4000K
	2530	72	Textured White	4000K	ON/OFF	12140	8971
141NF.28O9.830.AL	Oris 50mm opal recessed 80W CRI>80 90º IP40 ON/OFF 5Y 2810mm AL 3000K
	2810	80	Anodized aluminium	3000K	ON/OFF	12800	9452
141NF.28O9.830.TB	Oris 50mm opal recessed 80W CRI>80 90º IP40 ON/OFF 5Y 2810mm TB 3000K
	2810	80	Textured Black	3000K	ON/OFF	12800	9452
141NF.28O9.830.TW	Oris 50mm opal recessed 80W CRI>80 90º IP40 ON/OFF 5Y 2810mm TW 3000K
	2810	80	Textured White	3000K	ON/OFF	12800	9452
141NF.28O9.840.AL	Oris 50mm opal recessed 80W CRI>80 90º IP40 ON/OFF 5Y 2810mm AL 4000K
	2810	80	Anodized aluminium	4000K	ON/OFF	13480	9954
141NF.28O9.840.TB	Oris 50mm opal recessed 80W CRI>80 90º IP40 ON/OFF 5Y 2810mm TB 4000K
	2810	80	Textured Black	4000K	ON/OFF	13480	9954
141NF.28O9.840.TW	Oris 50mm opal recessed 80W CRI>80 90º IP40 ON/OFF 5Y 2810mm TW 4000K
	2810	80	Textured White	4000K	ON/OFF	13480	9954
141NF.30O9.830.AL	Oris 50mm opal recessed 88W CRI>80 90º IP40 ON/OFF 5Y 3090mm AL 3000K
	3090	88	Anodized aluminium	3000K	ON/OFF	14080	10357
141NF.30O9.830.TB	Oris 50mm opal recessed 88W CRI>80 90º IP40 ON/OFF 5Y 3090mm TB 3000K
	3090	88	Textured Black	3000K	ON/OFF	14080	10357
141NF.30O9.830.TW	Oris 50mm opal recessed 88W CRI>80 90º IP40 ON/OFF 5Y 3090mm TW 3000K
	3090	88	Textured White	3000K	ON/OFF	14080	10357
141NF.30O9.840.AL	Oris 50mm opal recessed 88W CRI>80 90º IP40 ON/OFF 5Y 3090mm AL 4000K
	3090	88	Anodized aluminium	4000K	ON/OFF	14840	10916
141NF.30O9.840.TB	Oris 50mm opal recessed 88W CRI>80 90º IP40 ON/OFF 5Y 3090mm TB 4000K
	3090	88	Textured Black	4000K	ON/OFF	14840	10916
141NF.30O9.840.TW	Oris 50mm opal recessed 88W CRI>80 90º IP40 ON/OFF 5Y 3090mm TW 4000K
	3090	88	Textured White	4000K	ON/OFF	14840	10916
141NF.33O9.830.AL	Oris 50mm opal recessed 96W CRI>80 90º IP40 ON/OFF 5Y 3370mm AL 3000K
	3370	96	Anodized aluminium	3000K	ON/OFF	15360	11262
141NF.33O9.830.TB	Oris 50mm opal recessed 96W CRI>80 90º IP40 ON/OFF 5Y 3370mm TB 3000K
	3370	96	Textured Black	3000K	ON/OFF	15360	11262
141NF.33O9.830.TW	Oris 50mm opal recessed 96W CRI>80 90º IP40 ON/OFF 5Y 3370mm TW 3000K
	3370	96	Textured White	3000K	ON/OFF	15360	11262
141NF.33O9.840.AL	Oris 50mm opal recessed 96W CRI>80 90º IP40 ON/OFF 5Y 3370mm AL 4000K
	3370	96	Anodized aluminium	4000K	ON/OFF	16200	11878
141NF.33O9.840.TB	Oris 50mm opal recessed 96W CRI>80 90º IP40 ON/OFF 5Y 3370mm TB 4000K
	3370	96	Textured Black	4000K	ON/OFF	16200	11878
141NF.33O9.840.TW	Oris 50mm opal recessed 96W CRI>80 90º IP40 ON/OFF 5Y 3370mm TW 4000K
	3370	96	Textured White	4000K	ON/OFF	16200	11878
141NF.39O9.830.AL	Oris 50mm opal recessed 112W CRI>80 90º IP40 ON/OFF 5Y 3930mm AL 3000K
	3930	112	Anodized aluminium	3000K	ON/OFF	17920	13239
141NF.39O9.830.TB	Oris 50mm opal recessed 112W CRI>80 90º IP40 ON/OFF 5Y 3930mm TB 3000K
	3930	112	Textured Black	3000K	ON/OFF	17920	13239
141NF.39O9.830.TW	Oris 50mm opal recessed 112W CRI>80 90º IP40 ON/OFF 5Y 3930mm TW 3000K
	3930	112	Textured White	3000K	ON/OFF	17920	13239
141NF.39O9.840.AL	Oris 50mm opal recessed 112W CRI>80 90º IP40 ON/OFF 5Y 3930mm AL 4000K
	3930	112	Anodized aluminium	4000K	ON/OFF	18880	13948
141NF.39O9.840.TB	Oris 50mm opal recessed 112W CRI>80 90º IP40 ON/OFF 5Y 3930mm TB 4000K
	3930	112	Textured Black	4000K	ON/OFF	18880	13948
141NF.39O9.840.TW	Oris 50mm opal recessed 112W CRI>80 90º IP40 ON/OFF 5Y 3930mm TW 4000K
	3930	112	Textured White	4000K	ON/OFF	18880	13948
141NF.44O9.830.AL	Oris 50mm opal recessed 128W CRI>80 90º IP40 ON/OFF 5Y 4490mm AL 3000K
	4490	128	Anodized aluminium	3000K	ON/OFF	20480	15083
141NF.44O9.830.TB	Oris 50mm opal recessed 128W CRI>80 90º IP40 ON/OFF 5Y 4490mm TB 3000K
	4490	128	Textured Black	3000K	ON/OFF	20480	15083
141NF.44O9.830.TW	Oris 50mm opal recessed 128W CRI>80 90º IP40 ON/OFF 5Y 4490mm TW 3000K
	4490	128	Textured White	3000K	ON/OFF	20480	15083
141NF.44O9.840.AL	Oris 50mm opal recessed 128W CRI>80 90º IP40 ON/OFF 5Y 4490mm AL 4000K
	4490	128	Anodized aluminium	4000K	ON/OFF	21580	15893
141NF.44O9.840.TB	Oris 50mm opal recessed 128W CRI>80 90º IP40 ON/OFF 5Y 4490mm TB 4000K
	4490	128	Textured Black	4000K	ON/OFF	21580	15893
141NF.44O9.840.TW	Oris 50mm opal recessed 128W CRI>80 90º IP40 ON/OFF 5Y 4490mm TW 4000K
	4490	128	Textured White	4000K	ON/OFF	21580	15893
141NF.50O9.830.AL	Oris 50mm opal recessed 144W CRI>80 90º IP40 ON/OFF 5Y 5050mm AL 3000K
	5050	144	Anodized aluminium	3000K	ON/OFF	23040	16893
141NF.50O9.830.TB	Oris 50mm opal recessed 144W CRI>80 90º IP40 ON/OFF 5Y 5050mm TB 3000K
	5050	144	Textured Black	3000K	ON/OFF	23040	16893
141NF.50O9.830.TW	Oris 50mm opal recessed 144W CRI>80 90º IP40 ON/OFF 5Y 5050mm TW 3000K
	5050	144	Textured White	3000K	ON/OFF	23040	16893
141NF.50O9.840.AL	Oris 50mm opal recessed 144W CRI>80 90º IP40 ON/OFF 5Y 5050mm AL 4000K
	5050	144	Anodized aluminium	4000K	ON/OFF	24300	17817
141NF.50O9.840.TB	Oris 50mm opal recessed 144W CRI>80 90º IP40 ON/OFF 5Y 5050mm TB 4000K
	5050	144	Textured Black	4000K	ON/OFF	24300	17817
141NF.50O9.840.TW	Oris 50mm opal recessed 144W CRI>80 90º IP40 ON/OFF 5Y 5050mm TW 4000K
	5050	144	Textured White	4000K	ON/OFF	24300	17817
141TW.08O9.82765.AL	Oris 50mm opal recessed 19,8W CRI>80 90º IP40 Tunable White 5Y 850mm AL 2700K -> 6500K
	850	19.8	Anodized aluminium	2700K - 6500K	Tunable White	3525	2553
141TW.08O9.82765.TB	Oris 50mm opal recessed 19,8W CRI>80 90º IP40 Tunable White 5Y 850mm TB 2700K -> 6500K
	850	19.8	Textured Black	2700K - 6500K	Tunable White	3525	2553
141TW.08O9.82765.TW	Oris 50mm opal recessed 19,8W CRI>80 90º IP40 Tunable White 5Y 850mm TW 2700K -> 6500K
	850	19.8	Textured White	2700K - 6500K	Tunable White	3525	2553
141TW.11O9.82765.AL	Oris 50mm opal recessed 26,4W CRI>80 90º IP40 Tunable White 5Y 1130mm AL 2700K -> 6500K
	1130	26.4	Anodized aluminium	2700K - 6500K	Tunable White	4700	3476
141TW.11O9.82765.TB	Oris 50mm opal recessed 26,4W CRI>80 90º IP40 Tunable White 5Y 1130mm TB 2700K -> 6500K
	1130	26.4	Textured Black	2700K - 6500K	Tunable White	4700	3476
141TW.11O9.82765.TW	Oris 50mm opal recessed 26,4W CRI>80 90º IP40 Tunable White 5Y 1130mm TW 2700K -> 6500K
	1130	26.4	Textured White	2700K - 6500K	Tunable White	4700	3476
141TW.14O9.82765.AL	Oris 50mm opal recessed 33W CRI>80 90º IP40 Tunable White 5Y 1410mm AL 2700K -> 6500K
	1410	33	Anodized aluminium	2700K - 6500K	Tunable White	5875	4339
141TW.14O9.82765.TB	Oris 50mm opal recessed 33W CRI>80 90º IP40 Tunable White 5Y 1410mm TB 2700K -> 6500K
	1410	33	Textured Black	2700K - 6500K	Tunable White	5875	4339
141TW.14O9.82765.TW	Oris 50mm opal recessed 33W CRI>80 90º IP40 Tunable White 5Y 1410mm TW 2700K -> 6500K
	1410	33	Textured White	2700K - 6500K	Tunable White	5875	4339
141TW.16O9.82765.AL	Oris 50mm opal recessed 39,6W CRI>80 90º IP40 Tunable White 5Y 1690mm AL 2700K -> 6500K
	1690	39.6	Anodized aluminium	2700K - 6500K	Tunable White	7050	5169
141TW.16O9.82765.TB	Oris 50mm opal recessed 39,6W CRI>80 90º IP40 Tunable White 5Y 1690mm TB 2700K -> 6500K
	1690	39.6	Textured Black	2700K - 6500K	Tunable White	7050	5169
141TW.16O9.82765.TW	Oris 50mm opal recessed 39,6W CRI>80 90º IP40 Tunable White 5Y 1690mm TW 2700K -> 6500K
	1690	39.6	Textured White	2700K - 6500K	Tunable White	7050	5169
141TW.19O9.82765.AL	Oris 50mm opal recessed 46,2W CRI>80 90º IP40 Tunable White 5Y 1970mm AL 2700K -> 6500K
	1970	46.2	Anodized aluminium	2700K - 6500K	Tunable White	8225	6029
141TW.19O9.82765.TB	Oris 50mm opal recessed 46,2W CRI>80 90º IP40 Tunable White 5Y 1970mm TB 2700K -> 6500K
	1970	46.2	Textured Black	2700K - 6500K	Tunable White	8225	6029
141TW.19O9.82765.TW	Oris 50mm opal recessed 46,2W CRI>80 90º IP40 Tunable White 5Y 1970mm TW 2700K -> 6500K
	1970	46.2	Textured White	2700K - 6500K	Tunable White	8225	6029
141TW.22O9.82765.AL	Oris 50mm opal recessed 52,8W CRI>80 90º IP40 Tunable White 5Y 2250mm AL 2700K -> 6500K
	2250	52.8	Anodized aluminium	2700K - 6500K	Tunable White	9400	6952
141TW.22O9.82765.TB	Oris 50mm opal recessed 52,8W CRI>80 90º IP40 Tunable White 5Y 2250mm TB 2700K -> 6500K
	2250	52.8	Textured Black	2700K - 6500K	Tunable White	9400	6952
141TW.22O9.82765.TW	Oris 50mm opal recessed 52,8W CRI>80 90º IP40 Tunable White 5Y 2250mm TW 2700K -> 6500K
	2250	52.8	Textured White	2700K - 6500K	Tunable White	9400	6952
141TW.25O9.82765.AL	Oris 50mm opal recessed 59,4W CRI>80 90º IP40 Tunable White 5Y 2530mm AL 2700K -> 6500K
	2530	59.4	Anodized aluminium	2700K - 6500K	Tunable White	10575	7815
141TW.25O9.82765.TB	Oris 50mm opal recessed 59,4W CRI>80 90º IP40 Tunable White 5Y 2530mm TB 2700K -> 6500K
	2530	59.4	Textured Black	2700K - 6500K	Tunable White	10575	7815
141TW.25O9.82765.TW	Oris 50mm opal recessed 59,4W CRI>80 90º IP40 Tunable White 5Y 2530mm TW 2700K -> 6500K
	2530	59.4	Textured White	2700K - 6500K	Tunable White	10575	7815
141TW.28O9.82765.AL	Oris 50mm opal recessed 66W CRI>80 90º IP40 Tunable White 5Y 2810mm AL 2700K -> 6500K
	2810	66	Anodized aluminium	2700K - 6500K	Tunable White	11750	8678
141TW.28O9.82765.TB	Oris 50mm opal recessed 66W CRI>80 90º IP40 Tunable White 5Y 2810mm TB 2700K -> 6500K
	2810	66	Textured Black	2700K - 6500K	Tunable White	11750	8678
141TW.28O9.82765.TW	Oris 50mm opal recessed 66W CRI>80 90º IP40 Tunable White 5Y 2810mm TW 2700K -> 6500K
	2810	66	Textured White	2700K - 6500K	Tunable White	11750	8678
141TW.30O9.82765.AL	Oris 50mm opal recessed 72,6W CRI>80 90º IP40 Tunable White 5Y 3090mm AL 2700K -> 6500K
	3090	72.6	Anodized aluminium	2700K - 6500K	Tunable White	12925	9508
141TW.30O9.82765.TB	Oris 50mm opal recessed 72,6W CRI>80 90º IP40 Tunable White 5Y 3090mm TB 2700K -> 6500K
	3090	72.6	Textured Black	2700K - 6500K	Tunable White	12925	9508
141TW.30O9.82765.TW	Oris 50mm opal recessed 72,6W CRI>80 90º IP40 Tunable White 5Y 3090mm TW 2700K -> 6500K
	3090	72.6	Textured White	2700K - 6500K	Tunable White	12925	9508
141TW.33O9.82765.AL	Oris 50mm opal recessed 79,2W CRI>80 90º IP40 Tunable White 5Y 3370mm AL 2700K -> 6500K
	3370	79.2	Anodized aluminium	2700K - 6500K	Tunable White	14100	10338
141TW.33O9.82765.TB	Oris 50mm opal recessed 79,2W CRI>80 90º IP40 Tunable White 5Y 3370mm TB 2700K -> 6500K
	3370	79.2	Textured Black	2700K - 6500K	Tunable White	14100	10338
141TW.33O9.82765.TW	Oris 50mm opal recessed 79,2W CRI>80 90º IP40 Tunable White 5Y 3370mm TW 2700K -> 6500K
	3370	79.2	Textured White	2700K - 6500K	Tunable White	14100	10338
141TW.39O9.82765.AL	Oris 50mm opal recessed 92,4W CRI>80 90º IP40 Tunable White 5Y 3930mm AL 2700K -> 6500K
	3930	92.4	Anodized aluminium	2700K - 6500K	Tunable White	16450	12154
141TW.39O9.82765.TB	Oris 50mm opal recessed 92,4W CRI>80 90º IP40 Tunable White 5Y 3930mm TB 2700K -> 6500K
	3930	92.4	Textured Black	2700K - 6500K	Tunable White	16450	12154
141TW.39O9.82765.TW	Oris 50mm opal recessed 92,4W CRI>80 90º IP40 Tunable White 5Y 3930mm TW 2700K -> 6500K
	3930	92.4	Textured White	2700K - 6500K	Tunable White	16450	12154
141TW.44O9.82765.AL	Oris 50mm opal recessed 105,6W CRI>80 90º IP40 Tunable White 5Y 4490mm AL 2700K -> 6500K
	4490	105.6	Anodized aluminium	2700K - 6500K	Tunable White	18800	13847
141TW.44O9.82765.TB	Oris 50mm opal recessed 105,6W CRI>80 90º IP40 Tunable White 5Y 4490mm TB 2700K -> 6500K
	4490	105.6	Textured Black	2700K - 6500K	Tunable White	18800	13847
141TW.44O9.82765.TW	Oris 50mm opal recessed 105,6W CRI>80 90º IP40 Tunable White 5Y 4490mm TW 2700K -> 6500K
	4490	105.6	Textured White	2700K - 6500K	Tunable White	18800	13847
141TW.50O9.82765.AL	Oris 50mm opal recessed 118,8W CRI>80 90º IP40 Tunable White 5Y 5050mm AL 2700K -> 6500K
	5050	118.8	Anodized aluminium	2700K - 6500K	Tunable White	21150	15507
141TW.50O9.82765.TB	Oris 50mm opal recessed 118,8W CRI>80 90º IP40 Tunable White 5Y 5050mm TB 2700K -> 6500K
	5050	118.8	Textured Black	2700K - 6500K	Tunable White	21150	15507
141TW.50O9.82765.TW	Oris 50mm opal recessed 118,8W CRI>80 90º IP40 Tunable White 5Y 5050mm TW 2700K -> 6500K
	5050	118.8	Textured White	2700K - 6500K	Tunable White	21150	15507
1741V.08O9.930.AL	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 1-10VDC 5Y 850mm AL 3000K
	850	23.4	Anodized aluminium	3000K	1-10V	3610	2615
1741V.08O9.930.TB	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 1-10VDC 5Y 850mm TB 3000K
	850	23.4	Textured Black	3000K	1-10V	3610	2615
1741V.08O9.930.TW	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 1-10VDC 5Y 850mm TW 3000K
	850	23.4	Textured White	3000K	1-10V	3610	2615
1741V.08O9.940.AL	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 1-10VDC 5Y 850mm AL 4000K
	850	23.4	Anodized aluminium	4000K	1-10V	3790	2745
1741V.08O9.940.TB	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 1-10VDC 5Y 850mm TB 4000K
	850	23.4	Textured Black	4000K	1-10V	3790	2745
1741V.08O9.940.TW	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 1-10VDC 5Y 850mm TW 4000K
	850	23.4	Textured White	4000K	1-10V	3790	2745
1741V.11O9.930.AL	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 1-10VDC 5Y 1130mm AL 3000K
	1130	31.2	Anodized aluminium	3000K	1-10V	4820	3565
1741V.11O9.930.TB	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 1-10VDC 5Y 1130mm TB 3000K
	1130	31.2	Textured Black	3000K	1-10V	4820	3565
1741V.11O9.930.TW	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 1-10VDC 5Y 1130mm TW 3000K
	1130	31.2	Textured White	3000K	1-10V	4820	3565
1741V.11O9.940.AL	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 1-10VDC 5Y 1130mm AL 4000K
	1130	31.2	Anodized aluminium	4000K	1-10V	5040	3728
1741V.11O9.940.TB	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 1-10VDC 5Y 1130mm TB 4000K
	1130	31.2	Textured Black	4000K	1-10V	5040	3728
1741V.11O9.940.TW	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 1-10VDC 5Y 1130mm TW 4000K
	1130	31.2	Textured White	4000K	1-10V	5040	3728
1741V.14O9.930.AL	Oris 50mm opal recessed 39W CRI>90 90º IP40 1-10VDC 5Y 1410mm AL 3000K
	1410	39	Anodized aluminium	3000K	1-10V	6020	4446
1741V.14O9.930.TB	Oris 50mm opal recessed 39W CRI>90 90º IP40 1-10VDC 5Y 1410mm TB 3000K
	1410	39	Textured Black	3000K	1-10V	6020	4446
1741V.14O9.930.TW	Oris 50mm opal recessed 39W CRI>90 90º IP40 1-10VDC 5Y 1410mm TW 3000K
	1410	39	Textured White	3000K	1-10V	6020	4446
1741V.14O9.940.AL	Oris 50mm opal recessed 39W CRI>90 90º IP40 1-10VDC 5Y 1410mm AL 4000K
	1410	39	Anodized aluminium	4000K	1-10V	6310	4660
1741V.14O9.940.TB	Oris 50mm opal recessed 39W CRI>90 90º IP40 1-10VDC 5Y 1410mm TB 4000K
	1410	39	Textured Black	4000K	1-10V	6310	4660
1741V.14O9.940.TW	Oris 50mm opal recessed 39W CRI>90 90º IP40 1-10VDC 5Y 1410mm TW 4000K
	1410	39	Textured White	4000K	1-10V	6310	4660
1741V.16O9.930.AL	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 1-10VDC 5Y 1690mm AL 3000K
	1690	46.8	Anodized aluminium	3000K	1-10V	7230	5301
1741V.16O9.930.TB	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 1-10VDC 5Y 1690mm TB 3000K
	1690	46.8	Textured Black	3000K	1-10V	7230	5301
1741V.16O9.930.TW	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 1-10VDC 5Y 1690mm TW 3000K
	1690	46.8	Textured White	3000K	1-10V	7230	5301
1741V.16O9.940.AL	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 1-10VDC 5Y 1690mm AL 4000K
	1690	46.8	Anodized aluminium	4000K	1-10V	7560	5543
1741V.16O9.940.TB	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 1-10VDC 5Y 1690mm TB 4000K
	1690	46.8	Textured Black	4000K	1-10V	7560	5543
1741V.16O9.940.TW	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 1-10VDC 5Y 1690mm TW 4000K
	1690	46.8	Textured White	4000K	1-10V	7560	5543
1741V.19O9.930.AL	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 1-10VDC 5Y 1970mm AL 3000K
	1970	54.6	Anodized aluminium	3000K	1-10V	8430	6180
1741V.19O9.930.TB	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 1-10VDC 5Y 1970mm TB 3000K
	1970	54.6	Textured Black	3000K	1-10V	8430	6180
1741V.19O9.930.TW	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 1-10VDC 5Y 1970mm TW 3000K
	1970	54.6	Textured White	3000K	1-10V	8430	6180
1741V.19O9.940.AL	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 1-10VDC 5Y 1970mm AL 4000K
	1970	54.6	Anodized aluminium	4000K	1-10V	8830	6473
1741V.19O9.940.TB	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 1-10VDC 5Y 1970mm TB 4000K
	1970	54.6	Textured Black	4000K	1-10V	8830	6473
1741V.19O9.940.TW	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 1-10VDC 5Y 1970mm TW 4000K
	1970	54.6	Textured White	4000K	1-10V	8830	6473
1741V.22O9.930.AL	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 1-10VDC 5Y 2250mm AL 3000K
	2250	62.4	Anodized aluminium	3000K	1-10V	9640	7130
1741V.22O9.930.TB	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 1-10VDC 5Y 2250mm TB 3000K
	2250	62.4	Textured Black	3000K	1-10V	9640	7130
1741V.22O9.930.TW	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 1-10VDC 5Y 2250mm TW 3000K
	2250	62.4	Textured White	3000K	1-10V	9640	7130
1741V.22O9.940.AL	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 1-10VDC 5Y 2250mm AL 4000K
	2250	62.4	Anodized aluminium	4000K	1-10V	10080	7456
1741V.22O9.940.TB	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 1-10VDC 5Y 2250mm TB 4000K
	2250	62.4	Textured Black	4000K	1-10V	10080	7456
1741V.22O9.940.TW	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 1-10VDC 5Y 2250mm TW 4000K
	2250	62.4	Textured White	4000K	1-10V	10080	7456
1741V.25O9.930.AL	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 1-10VDC 5Y 2530mm AL 3000K
	2530	70.2	Anodized aluminium	3000K	1-10V	10840	8011
1741V.25O9.930.TB	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 1-10VDC 5Y 2530mm TB 3000K
	2530	70.2	Textured Black	3000K	1-10V	10840	8011
1741V.25O9.930.TW	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 1-10VDC 5Y 2530mm TW 3000K
	2530	70.2	Textured White	3000K	1-10V	10840	8011
1741V.25O9.940.AL	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 1-10VDC 5Y 2530mm AL 4000K
	2530	70.2	Anodized aluminium	4000K	1-10V	11350	8388
1741V.25O9.940.TB	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 1-10VDC 5Y 2530mm TB 4000K
	2530	70.2	Textured Black	4000K	1-10V	11350	8388
1741V.25O9.940.TW	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 1-10VDC 5Y 2530mm TW 4000K
	2530	70.2	Textured White	4000K	1-10V	11350	8388
1741V.28O9.930.AL	Oris 50mm opal recessed 78W CRI>90 90º IP40 1-10VDC 5Y 2810mm AL 3000K
	2810	78	Anodized aluminium	3000K	1-10V	12040	8892
1741V.28O9.930.TB	Oris 50mm opal recessed 78W CRI>90 90º IP40 1-10VDC 5Y 2810mm TB 3000K
	2810	78	Textured Black	3000K	1-10V	12040	8892
1741V.28O9.930.TW	Oris 50mm opal recessed 78W CRI>90 90º IP40 1-10VDC 5Y 2810mm TW 3000K
	2810	78	Textured White	3000K	1-10V	12040	8892
1741V.28O9.940.AL	Oris 50mm opal recessed 78W CRI>90 90º IP40 1-10VDC 5Y 2810mm AL 4000K
	2810	78	Anodized aluminium	4000K	1-10V	12620	9320
1741V.28O9.940.TB	Oris 50mm opal recessed 78W CRI>90 90º IP40 1-10VDC 5Y 2810mm TB 4000K
	2810	78	Textured Black	4000K	1-10V	12620	9320
1741V.28O9.940.TW	Oris 50mm opal recessed 78W CRI>90 90º IP40 1-10VDC 5Y 2810mm TW 4000K
	2810	78	Textured White	4000K	1-10V	12620	9320
1741V.30O9.930.AL	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 1-10VDC 5Y 3090mm AL 3000K
	3090	85.8	Anodized aluminium	3000K	1-10V	13250	9747
1741V.30O9.930.TB	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 1-10VDC 5Y 3090mm TB 3000K
	3090	85.8	Textured Black	3000K	1-10V	13250	9747
1741V.30O9.930.TW	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 1-10VDC 5Y 3090mm TW 3000K
	3090	85.8	Textured White	3000K	1-10V	13250	9747
1741V.30O9.940.AL	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 1-10VDC 5Y 3090mm AL 4000K
	3090	85.8	Anodized aluminium	4000K	1-10V	13870	10203
1741V.30O9.940.TB	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 1-10VDC 5Y 3090mm TB 4000K
	3090	85.8	Textured Black	4000K	1-10V	13870	10203
1741V.30O9.940.TW	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 1-10VDC 5Y 3090mm TW 4000K
	3090	85.8	Textured White	4000K	1-10V	13870	10203
1741V.33O9.930.AL	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 1-10VDC 5Y 3370mm AL 3000K
	3370	93.6	Anodized aluminium	3000K	1-10V	14460	10602
1741V.33O9.930.TB	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 1-10VDC 5Y 3370mm TB 3000K
	3370	93.6	Textured Black	3000K	1-10V	14460	10602
1741V.33O9.930.TW	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 1-10VDC 5Y 3370mm TW 3000K
	3370	93.6	Textured White	3000K	1-10V	14460	10602
1741V.33O9.940.AL	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 1-10VDC 5Y 3370mm AL 4000K
	3370	93.6	Anodized aluminium	4000K	1-10V	15120	11086
1741V.33O9.940.TB	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 1-10VDC 5Y 3370mm TB 4000K
	3370	93.6	Textured Black	4000K	1-10V	15120	11086
1741V.33O9.940.TW	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 1-10VDC 5Y 3370mm TW 4000K
	3370	93.6	Textured White	4000K	1-10V	15120	11086
1741V.39O9.930.AL	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 1-10VDC 5Y 3930mm AL 3000K
	3930	109.2	Anodized aluminium	3000K	1-10V	16860	12457
1741V.39O9.930.TB	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 1-10VDC 5Y 3930mm TB 3000K
	3930	109.2	Textured Black	3000K	1-10V	16860	12457
1741V.39O9.930.TW	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 1-10VDC 5Y 3930mm TW 3000K
	3930	109.2	Textured White	3000K	1-10V	16860	12457
1741V.39O9.940.AL	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 1-10VDC 5Y 3930mm AL 4000K
	3930	109.2	Anodized aluminium	4000K	1-10V	17660	13048
1741V.39O9.940.TB	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 1-10VDC 5Y 3930mm TB 4000K
	3930	109.2	Textured Black	4000K	1-10V	17660	13048
1741V.39O9.940.TW	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 1-10VDC 5Y 3930mm TW 4000K
	3930	109.2	Textured White	4000K	1-10V	17660	13048
1741V.44O9.930.AL	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 1-10VDC 5Y 4490mm AL 3000K
	4490	124.8	Anodized aluminium	3000K	1-10V	19270	14193
1741V.44O9.930.TB	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 1-10VDC 5Y 4490mm TB 3000K
	4490	124.8	Textured Black	3000K	1-10V	19270	14193
1741V.44O9.930.TW	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 1-10VDC 5Y 4490mm TW 3000K
	4490	124.8	Textured White	3000K	1-10V	19270	14193
1741V.44O9.940.AL	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 1-10VDC 5Y 4490mm AL 4000K
	4490	124.8	Anodized aluminium	4000K	1-10V	20180	14863
1741V.44O9.940.TB	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 1-10VDC 5Y 4490mm TB 4000K
	4490	124.8	Textured Black	4000K	1-10V	20180	14863
1741V.44O9.940.TW	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 1-10VDC 5Y 4490mm TW 4000K
	4490	124.8	Textured White	4000K	1-10V	20180	14863
1741V.50O9.930.AL	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 1-10VDC 5Y 5050mm AL 3000K
	5050	140.4	Anodized aluminium	3000K	1-10V	21690	15903
1741V.50O9.930.TB	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 1-10VDC 5Y 5050mm TB 3000K
	5050	140.4	Textured Black	3000K	1-10V	21690	15903
1741V.50O9.930.TW	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 1-10VDC 5Y 5050mm TW 3000K
	5050	140.4	Textured White	3000K	1-10V	21690	15903
1741V.50O9.940.AL	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 1-10VDC 5Y 5050mm AL 4000K
	5050	140.4	Anodized aluminium	4000K	1-10V	22680	16629
1741V.50O9.940.TB	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 1-10VDC 5Y 5050mm TB 4000K
	5050	140.4	Textured Black	4000K	1-10V	22680	16629
1741V.50O9.940.TW	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 1-10VDC 5Y 5050mm TW 4000K
	5050	140.4	Textured White	4000K	1-10V	22680	16629
174DA.08O9.930.AL	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 DALI Push dim 5Y 850mm AL 3000K
	850	23.4	Anodized aluminium	3000K	DALI / Switch Dim	3610	2615
174DA.08O9.930.TB	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 DALI Push dim 5Y 850mm TB 3000K
	850	23.4	Textured Black	3000K	DALI / Switch Dim	3610	2615
174DA.08O9.930.TW	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 DALI Push dim 5Y 850mm TW 3000K
	850	23.4	Textured White	3000K	DALI / Switch Dim	3610	2615
174DA.08O9.940.AL	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 DALI Push dim 5Y 850mm AL 4000K
	850	23.4	Anodized aluminium	4000K	DALI / Switch Dim	3790	2745
174DA.08O9.940.TB	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 DALI Push dim 5Y 850mm TB 4000K
	850	23.4	Textured Black	4000K	DALI / Switch Dim	3790	2745
174DA.08O9.940.TW	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 DALI Push dim 5Y 850mm TW 4000K
	850	23.4	Textured White	4000K	DALI / Switch Dim	3790	2745
174DA.11O9.930.AL	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 DALI Push dim 5Y 1130mm AL 3000K
	1130	31.2	Anodized aluminium	3000K	DALI / Switch Dim	4820	3565
174DA.11O9.930.TB	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 DALI Push dim 5Y 1130mm TB 3000K
	1130	31.2	Textured Black	3000K	DALI / Switch Dim	4820	3565
174DA.11O9.930.TW	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 DALI Push dim 5Y 1130mm TW 3000K
	1130	31.2	Textured White	3000K	DALI / Switch Dim	4820	3565
174DA.11O9.940.AL	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 DALI Push dim 5Y 1130mm AL 4000K
	1130	31.2	Anodized aluminium	4000K	DALI / Switch Dim	5040	3728
174DA.11O9.940.TB	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 DALI Push dim 5Y 1130mm TB 4000K
	1130	31.2	Textured Black	4000K	DALI / Switch Dim	5040	3728
174DA.11O9.940.TW	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 DALI Push dim 5Y 1130mm TW 4000K
	1130	31.2	Textured White	4000K	DALI / Switch Dim	5040	3728
174DA.14O9.930.AL	Oris 50mm opal recessed 39W CRI>90 90º IP40 DALI Push dim 5Y 1410mm AL 3000K
	1410	39	Anodized aluminium	3000K	DALI / Switch Dim	6020	4446
174DA.14O9.930.TB	Oris 50mm opal recessed 39W CRI>90 90º IP40 DALI Push dim 5Y 1410mm TB 3000K
	1410	39	Textured Black	3000K	DALI / Switch Dim	6020	4446
174DA.14O9.930.TW	Oris 50mm opal recessed 39W CRI>90 90º IP40 DALI Push dim 5Y 1410mm TW 3000K
	1410	39	Textured White	3000K	DALI / Switch Dim	6020	4446
174DA.14O9.940.AL	Oris 50mm opal recessed 39W CRI>90 90º IP40 DALI Push dim 5Y 1410mm AL 4000K
	1410	39	Anodized aluminium	4000K	DALI / Switch Dim	6310	4660
174DA.14O9.940.TB	Oris 50mm opal recessed 39W CRI>90 90º IP40 DALI Push dim 5Y 1410mm TB 4000K
	1410	39	Textured Black	4000K	DALI / Switch Dim	6310	4660
174DA.14O9.940.TW	Oris 50mm opal recessed 39W CRI>90 90º IP40 DALI Push dim 5Y 1410mm TW 4000K
	1410	39	Textured White	4000K	DALI / Switch Dim	6310	4660
174DA.16O9.930.AL	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 DALI Push dim 5Y 1690mm AL 3000K
	1690	46.8	Anodized aluminium	3000K	DALI / Switch Dim	7230	5301
174DA.16O9.930.TB	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 DALI Push dim 5Y 1690mm TB 3000K
	1690	46.8	Textured Black	3000K	DALI / Switch Dim	7230	5301
174DA.16O9.930.TW	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 DALI Push dim 5Y 1690mm TW 3000K
	1690	46.8	Textured White	3000K	DALI / Switch Dim	7230	5301
174DA.16O9.940.AL	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 DALI Push dim 5Y 1690mm AL 4000K
	1690	46.8	Anodized aluminium	4000K	DALI / Switch Dim	7560	5543
174DA.16O9.940.TB	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 DALI Push dim 5Y 1690mm TB 4000K
	1690	46.8	Textured Black	4000K	DALI / Switch Dim	7560	5543
174DA.16O9.940.TW	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 DALI Push dim 5Y 1690mm TW 4000K
	1690	46.8	Textured White	4000K	DALI / Switch Dim	7560	5543
174DA.19O9.930.AL	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 DALI Push dim 5Y 1970mm AL 3000K
	1970	54.6	Anodized aluminium	3000K	DALI / Switch Dim	8430	6180
174DA.19O9.930.TB	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 DALI Push dim 5Y 1970mm TB 3000K
	1970	54.6	Textured Black	3000K	DALI / Switch Dim	8430	6180
174DA.19O9.930.TW	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 DALI Push dim 5Y 1970mm TW 3000K
	1970	54.6	Textured White	3000K	DALI / Switch Dim	8430	6180
174DA.19O9.940.AL	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 DALI Push dim 5Y 1970mm AL 4000K
	1970	54.6	Anodized aluminium	4000K	DALI / Switch Dim	8830	6473
174DA.19O9.940.TB	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 DALI Push dim 5Y 1970mm TB 4000K
	1970	54.6	Textured Black	4000K	DALI / Switch Dim	8830	6473
174DA.19O9.940.TW	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 DALI Push dim 5Y 1970mm TW 4000K
	1970	54.6	Textured White	4000K	DALI / Switch Dim	8830	6473
174DA.22O9.930.AL	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 DALI Push dim 5Y 2250mm AL 3000K
	2250	62.4	Anodized aluminium	3000K	DALI / Switch Dim	9640	7130
174DA.22O9.930.TB	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 DALI Push dim 5Y 2250mm TB 3000K
	2250	62.4	Textured Black	3000K	DALI / Switch Dim	9640	7130
174DA.22O9.930.TW	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 DALI Push dim 5Y 2250mm TW 3000K
	2250	62.4	Textured White	3000K	DALI / Switch Dim	9640	7130
174DA.22O9.940.AL	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 DALI Push dim 5Y 2250mm AL 4000K
	2250	62.4	Anodized aluminium	4000K	DALI / Switch Dim	10080	7456
174DA.22O9.940.TB	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 DALI Push dim 5Y 2250mm TB 4000K
	2250	62.4	Textured Black	4000K	DALI / Switch Dim	10080	7456
174DA.22O9.940.TW	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 DALI Push dim 5Y 2250mm TW 4000K
	2250	62.4	Textured White	4000K	DALI / Switch Dim	10080	7456
174DA.25O9.930.AL	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 DALI Push dim 5Y 2530mm AL 3000K
	2530	70.2	Anodized aluminium	3000K	DALI / Switch Dim	10840	8011
174DA.25O9.930.TB	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 DALI Push dim 5Y 2530mm TB 3000K
	2530	70.2	Textured Black	3000K	DALI / Switch Dim	10840	8011
174DA.25O9.930.TW	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 DALI Push dim 5Y 2530mm TW 3000K
	2530	70.2	Textured White	3000K	DALI / Switch Dim	10840	8011
174DA.25O9.940.AL	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 DALI Push dim 5Y 2530mm AL 4000K
	2530	70.2	Anodized aluminium	4000K	DALI / Switch Dim	11350	8388
174DA.25O9.940.TB	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 DALI Push dim 5Y 2530mm TB 4000K
	2530	70.2	Textured Black	4000K	DALI / Switch Dim	11350	8388
174DA.25O9.940.TW	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 DALI Push dim 5Y 2530mm TW 4000K
	2530	70.2	Textured White	4000K	DALI / Switch Dim	11350	8388
174DA.28O9.930.AL	Oris 50mm opal recessed 78W CRI>90 90º IP40 DALI Push dim 5Y 2810mm AL 3000K
	2810	78	Anodized aluminium	3000K	DALI / Switch Dim	12040	8892
174DA.28O9.930.TB	Oris 50mm opal recessed 78W CRI>90 90º IP40 DALI Push dim 5Y 2810mm TB 3000K
	2810	78	Textured Black	3000K	DALI / Switch Dim	12040	8892
174DA.28O9.930.TW	Oris 50mm opal recessed 78W CRI>90 90º IP40 DALI Push dim 5Y 2810mm TW 3000K
	2810	78	Textured White	3000K	DALI / Switch Dim	12040	8892
174DA.28O9.940.AL	Oris 50mm opal recessed 78W CRI>90 90º IP40 DALI Push dim 5Y 2810mm AL 4000K
	2810	78	Anodized aluminium	4000K	DALI / Switch Dim	12620	9320
174DA.28O9.940.TB	Oris 50mm opal recessed 78W CRI>90 90º IP40 DALI Push dim 5Y 2810mm TB 4000K
	2810	78	Textured Black	4000K	DALI / Switch Dim	12620	9320
174DA.28O9.940.TW	Oris 50mm opal recessed 78W CRI>90 90º IP40 DALI Push dim 5Y 2810mm TW 4000K
	2810	78	Textured White	4000K	DALI / Switch Dim	12620	9320
174DA.30O9.930.AL	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 DALI Push dim 5Y 3090mm AL 3000K
	3090	85.8	Anodized aluminium	3000K	DALI / Switch Dim	13250	9747
174DA.30O9.930.TB	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 DALI Push dim 5Y 3090mm TB 3000K
	3090	85.8	Textured Black	3000K	DALI / Switch Dim	13250	9747
174DA.30O9.930.TW	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 DALI Push dim 5Y 3090mm TW 3000K
	3090	85.8	Textured White	3000K	DALI / Switch Dim	13250	9747
174DA.30O9.940.AL	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 DALI Push dim 5Y 3090mm AL 4000K
	3090	85.8	Anodized aluminium	4000K	DALI / Switch Dim	13870	10203
174DA.30O9.940.TB	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 DALI Push dim 5Y 3090mm TB 4000K
	3090	85.8	Textured Black	4000K	DALI / Switch Dim	13870	10203
174DA.30O9.940.TW	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 DALI Push dim 5Y 3090mm TW 4000K
	3090	85.8	Textured White	4000K	DALI / Switch Dim	13870	10203
174DA.33O9.930.AL	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 DALI Push dim 5Y 3370mm AL 3000K
	3370	93.6	Anodized aluminium	3000K	DALI / Switch Dim	14460	10602
174DA.33O9.930.TB	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 DALI Push dim 5Y 3370mm TB 3000K
	3370	93.6	Textured Black	3000K	DALI / Switch Dim	14460	10602
174DA.33O9.930.TW	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 DALI Push dim 5Y 3370mm TW 3000K
	3370	93.6	Textured White	3000K	DALI / Switch Dim	14460	10602
174DA.33O9.940.AL	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 DALI Push dim 5Y 3370mm AL 4000K
	3370	93.6	Anodized aluminium	4000K	DALI / Switch Dim	15120	11086
174DA.33O9.940.TB	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 DALI Push dim 5Y 3370mm TB 4000K
	3370	93.6	Textured Black	4000K	DALI / Switch Dim	15120	11086
174DA.33O9.940.TW	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 DALI Push dim 5Y 3370mm TW 4000K
	3370	93.6	Textured White	4000K	DALI / Switch Dim	15120	11086
174DA.39O9.930.AL	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 DALI Push dim 5Y 3930mm AL 3000K
	3930	109.2	Anodized aluminium	3000K	DALI / Switch Dim	16860	12457
174DA.39O9.930.TB	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 DALI Push dim 5Y 3930mm TB 3000K
	3930	109.2	Textured Black	3000K	DALI / Switch Dim	16860	12457
174DA.39O9.930.TW	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 DALI Push dim 5Y 3930mm TW 3000K
	3930	109.2	Textured White	3000K	DALI / Switch Dim	16860	12457
174DA.39O9.940.AL	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 DALI Push dim 5Y 3930mm AL 4000K
	3930	109.2	Anodized aluminium	4000K	DALI / Switch Dim	17660	13048
174DA.39O9.940.TB	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 DALI Push dim 5Y 3930mm TB 4000K
	3930	109.2	Textured Black	4000K	DALI / Switch Dim	17660	13048
174DA.39O9.940.TW	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 DALI Push dim 5Y 3930mm TW 4000K
	3930	109.2	Textured White	4000K	DALI / Switch Dim	17660	13048
174DA.44O9.930.AL	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 DALI Push dim 5Y 4490mm AL 3000K
	4490	124.8	Anodized aluminium	3000K	DALI / Switch Dim	19270	14193
174DA.44O9.930.TB	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 DALI Push dim 5Y 4490mm TB 3000K
	4490	124.8	Textured Black	3000K	DALI / Switch Dim	19270	14193
174DA.44O9.930.TW	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 DALI Push dim 5Y 4490mm TW 3000K
	4490	124.8	Textured White	3000K	DALI / Switch Dim	19270	14193
174DA.44O9.940.AL	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 DALI Push dim 5Y 4490mm AL 4000K
	4490	124.8	Anodized aluminium	4000K	DALI / Switch Dim	20180	14863
174DA.44O9.940.TB	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 DALI Push dim 5Y 4490mm TB 4000K
	4490	124.8	Textured Black	4000K	DALI / Switch Dim	20180	14863
174DA.44O9.940.TW	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 DALI Push dim 5Y 4490mm TW 4000K
	4490	124.8	Textured White	4000K	DALI / Switch Dim	20180	14863
174DA.50O9.930.AL	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 DALI Push dim 5Y 5050mm AL 3000K
	5050	140.4	Anodized aluminium	3000K	DALI / Switch Dim	21690	15903
174DA.50O9.930.TB	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 DALI Push dim 5Y 5050mm TB 3000K
	5050	140.4	Textured Black	3000K	DALI / Switch Dim	21690	15903
174DA.50O9.930.TW	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 DALI Push dim 5Y 5050mm TW 3000K
	5050	140.4	Textured White	3000K	DALI / Switch Dim	21690	15903
174DA.50O9.940.AL	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 DALI Push dim 5Y 5050mm AL 4000K
	5050	140.4	Anodized aluminium	4000K	DALI / Switch Dim	22680	16629
174DA.50O9.940.TB	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 DALI Push dim 5Y 5050mm TB 4000K
	5050	140.4	Textured Black	4000K	DALI / Switch Dim	22680	16629
174DA.50O9.940.TW	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 DALI Push dim 5Y 5050mm TW 4000K
	5050	140.4	Textured White	4000K	DALI / Switch Dim	22680	16629
174NF.08O9.930.AL	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 ON/OFF 5Y 850mm AL 3000K
	850	23.4	Anodized aluminium	3000K	ON/OFF	3610	2615
174NF.08O9.930.TB	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 ON/OFF 5Y 850mm TB 3000K
	850	23.4	Textured Black	3000K	ON/OFF	3610	2615
174NF.08O9.930.TW	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 ON/OFF 5Y 850mm TW 3000K
	850	23.4	Textured White	3000K	ON/OFF	3610	2615
174NF.08O9.940.AL	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 ON/OFF 5Y 850mm AL 4000K
	850	23.4	Anodized aluminium	4000K	ON/OFF	3790	2745
174NF.08O9.940.TB	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 ON/OFF 5Y 850mm TB 4000K
	850	23.4	Textured Black	4000K	ON/OFF	3790	2745
174NF.08O9.940.TW	Oris 50mm opal recessed 23,4W CRI>90 90º IP40 ON/OFF 5Y 850mm TW 4000K
	850	23.4	Textured White	4000K	ON/OFF	3790	2745
174NF.11O9.930.AL	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 ON/OFF 5Y 1130mm AL 3000K
	1130	31.2	Anodized aluminium	3000K	ON/OFF	4820	3565
174NF.11O9.930.TB	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 ON/OFF 5Y 1130mm TB 3000K
	1130	31.2	Textured Black	3000K	ON/OFF	4820	3565
174NF.11O9.930.TW	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 ON/OFF 5Y 1130mm TW 3000K
	1130	31.2	Textured White	3000K	ON/OFF	4820	3565
174NF.11O9.940.AL	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 ON/OFF 5Y 1130mm AL 4000K
	1130	31.2	Anodized aluminium	4000K	ON/OFF	5040	3728
174NF.11O9.940.TB	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 ON/OFF 5Y 1130mm TB 4000K
	1130	31.2	Textured Black	4000K	ON/OFF	5040	3728
174NF.11O9.940.TW	Oris 50mm opal recessed 31,2W CRI>90 90º IP40 ON/OFF 5Y 1130mm TW 4000K
	1130	31.2	Textured White	4000K	ON/OFF	5040	3728
174NF.14O9.930.AL	Oris 50mm opal recessed 39W CRI>90 90º IP40 ON/OFF 5Y 1410mm AL 3000K
	1410	39	Anodized aluminium	3000K	ON/OFF	6020	4446
174NF.14O9.930.TB	Oris 50mm opal recessed 39W CRI>90 90º IP40 ON/OFF 5Y 1410mm TB 3000K
	1410	39	Textured Black	3000K	ON/OFF	6020	4446
174NF.14O9.930.TW	Oris 50mm opal recessed 39W CRI>90 90º IP40 ON/OFF 5Y 1410mm TW 3000K
	1410	39	Textured White	3000K	ON/OFF	6020	4446
174NF.14O9.940.AL	Oris 50mm opal recessed 39W CRI>90 90º IP40 ON/OFF 5Y 1410mm AL 4000K
	1410	39	Anodized aluminium	4000K	ON/OFF	6310	4660
174NF.14O9.940.TB	Oris 50mm opal recessed 39W CRI>90 90º IP40 ON/OFF 5Y 1410mm TB 4000K
	1410	39	Textured Black	4000K	ON/OFF	6310	4660
174NF.14O9.940.TW	Oris 50mm opal recessed 39W CRI>90 90º IP40 ON/OFF 5Y 1410mm TW 4000K
	1410	39	Textured White	4000K	ON/OFF	6310	4660
174NF.16O9.930.AL	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 ON/OFF 5Y 1690mm AL 3000K
	1690	46.8	Anodized aluminium	3000K	ON/OFF	7230	5301
174NF.16O9.930.TB	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 ON/OFF 5Y 1690mm TB 3000K
	1690	46.8	Textured Black	3000K	ON/OFF	7230	5301
174NF.16O9.930.TW	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 ON/OFF 5Y 1690mm TW 3000K
	1690	46.8	Textured White	3000K	ON/OFF	7230	5301
174NF.16O9.940.AL	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 ON/OFF 5Y 1690mm AL 4000K
	1690	46.8	Anodized aluminium	4000K	ON/OFF	7560	5543
174NF.16O9.940.TB	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 ON/OFF 5Y 1690mm TB 4000K
	1690	46.8	Textured Black	4000K	ON/OFF	7560	5543
174NF.16O9.940.TW	Oris 50mm opal recessed 46,8W CRI>90 90º IP40 ON/OFF 5Y 1690mm TW 4000K
	1690	46.8	Textured White	4000K	ON/OFF	7560	5543
174NF.19O9.930.AL	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 ON/OFF 5Y 1970mm AL 3000K
	1970	54.6	Anodized aluminium	3000K	ON/OFF	8430	6180
174NF.19O9.930.TB	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 ON/OFF 5Y 1970mm TB 3000K
	1970	54.6	Textured Black	3000K	ON/OFF	8430	6180
174NF.19O9.930.TW	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 ON/OFF 5Y 1970mm TW 3000K
	1970	54.6	Textured White	3000K	ON/OFF	8430	6180
174NF.19O9.940.AL	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 ON/OFF 5Y 1970mm AL 4000K
	1970	54.6	Anodized aluminium	4000K	ON/OFF	8830	6473
174NF.19O9.940.TB	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 ON/OFF 5Y 1970mm TB 4000K
	1970	54.6	Textured Black	4000K	ON/OFF	8830	6473
174NF.19O9.940.TW	Oris 50mm opal recessed 54,6W CRI>90 90º IP40 ON/OFF 5Y 1970mm TW 4000K
	1970	54.6	Textured White	4000K	ON/OFF	8830	6473
174NF.22O9.930.AL	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 ON/OFF 5Y 2250mm AL 3000K
	2250	62.4	Anodized aluminium	3000K	ON/OFF	9640	7130
174NF.22O9.930.TB	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 ON/OFF 5Y 2250mm TB 3000K
	2250	62.4	Textured Black	3000K	ON/OFF	9640	7130
174NF.22O9.930.TW	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 ON/OFF 5Y 2250mm TW 3000K
	2250	62.4	Textured White	3000K	ON/OFF	9640	7130
174NF.22O9.940.AL	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 ON/OFF 5Y 2250mm AL 4000K
	2250	62.4	Anodized aluminium	4000K	ON/OFF	10080	7456
174NF.22O9.940.TB	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 ON/OFF 5Y 2250mm TB 4000K
	2250	62.4	Textured Black	4000K	ON/OFF	10080	7456
174NF.22O9.940.TW	Oris 50mm opal recessed 62,4W CRI>90 90º IP40 ON/OFF 5Y 2250mm TW 4000K
	2250	62.4	Textured White	4000K	ON/OFF	10080	7456
174NF.25O9.930.AL	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 ON/OFF 5Y 2530mm AL 3000K
	2530	70.2	Anodized aluminium	3000K	ON/OFF	10840	8011
174NF.25O9.930.TB	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 ON/OFF 5Y 2530mm TB 3000K
	2530	70.2	Textured Black	3000K	ON/OFF	10840	8011
174NF.25O9.930.TW	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 ON/OFF 5Y 2530mm TW 3000K
	2530	70.2	Textured White	3000K	ON/OFF	10840	8011
174NF.25O9.940.AL	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 ON/OFF 5Y 2530mm AL 4000K
	2530	70.2	Anodized aluminium	4000K	ON/OFF	11350	8388
174NF.25O9.940.TB	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 ON/OFF 5Y 2530mm TB 4000K
	2530	70.2	Textured Black	4000K	ON/OFF	11350	8388
174NF.25O9.940.TW	Oris 50mm opal recessed 70,2W CRI>90 90º IP40 ON/OFF 5Y 2530mm TW 4000K
	2530	70.2	Textured White	4000K	ON/OFF	11350	8388
174NF.28O9.930.AL	Oris 50mm opal recessed 78W CRI>90 90º IP40 ON/OFF 5Y 2810mm AL 3000K
	2810	78	Anodized aluminium	3000K	ON/OFF	12040	8892
174NF.28O9.930.TB	Oris 50mm opal recessed 78W CRI>90 90º IP40 ON/OFF 5Y 2810mm TB 3000K
	2810	78	Textured Black	3000K	ON/OFF	12040	8892
174NF.28O9.930.TW	Oris 50mm opal recessed 78W CRI>90 90º IP40 ON/OFF 5Y 2810mm TW 3000K
	2810	78	Textured White	3000K	ON/OFF	12040	8892
174NF.28O9.940.AL	Oris 50mm opal recessed 78W CRI>90 90º IP40 ON/OFF 5Y 2810mm AL 4000K
	2810	78	Anodized aluminium	4000K	ON/OFF	12620	9320
174NF.28O9.940.TB	Oris 50mm opal recessed 78W CRI>90 90º IP40 ON/OFF 5Y 2810mm TB 4000K
	2810	78	Textured Black	4000K	ON/OFF	12620	9320
174NF.28O9.940.TW	Oris 50mm opal recessed 78W CRI>90 90º IP40 ON/OFF 5Y 2810mm TW 4000K
	2810	78	Textured White	4000K	ON/OFF	12620	9320
174NF.30O9.930.AL	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 ON/OFF 5Y 3090mm AL 3000K
	3090	85.8	Anodized aluminium	3000K	ON/OFF	13250	9747
174NF.30O9.930.TB	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 ON/OFF 5Y 3090mm TB 3000K
	3090	85.8	Textured Black	3000K	ON/OFF	13250	9747
174NF.30O9.930.TW	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 ON/OFF 5Y 3090mm TW 3000K
	3090	85.8	Textured White	3000K	ON/OFF	13250	9747
174NF.30O9.940.AL	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 ON/OFF 5Y 3090mm AL 4000K
	3090	85.8	Anodized aluminium	4000K	ON/OFF	13870	10203
174NF.30O9.940.TB	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 ON/OFF 5Y 3090mm TB 4000K
	3090	85.8	Textured Black	4000K	ON/OFF	13870	10203
174NF.30O9.940.TW	Oris 50mm opal recessed 85,8W CRI>90 90º IP40 ON/OFF 5Y 3090mm TW 4000K
	3090	85.8	Textured White	4000K	ON/OFF	13870	10203
174NF.33O9.930.AL	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 ON/OFF 5Y 3370mm AL 3000K
	3370	93.6	Anodized aluminium	3000K	ON/OFF	14460	10602
174NF.33O9.930.TB	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 ON/OFF 5Y 3370mm TB 3000K
	3370	93.6	Textured Black	3000K	ON/OFF	14460	10602
174NF.33O9.930.TW	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 ON/OFF 5Y 3370mm TW 3000K
	3370	93.6	Textured White	3000K	ON/OFF	14460	10602
174NF.33O9.940.AL	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 ON/OFF 5Y 3370mm AL 4000K
	3370	93.6	Anodized aluminium	4000K	ON/OFF	15120	11086
174NF.33O9.940.TB	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 ON/OFF 5Y 3370mm TB 4000K
	3370	93.6	Textured Black	4000K	ON/OFF	15120	11086
174NF.33O9.940.TW	Oris 50mm opal recessed 93,6W CRI>90 90º IP40 ON/OFF 5Y 3370mm TW 4000K
	3370	93.6	Textured White	4000K	ON/OFF	15120	11086
174NF.39O9.930.AL	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 ON/OFF 5Y 3930mm AL 3000K
	3930	109.2	Anodized aluminium	3000K	ON/OFF	16860	12457
174NF.39O9.930.TB	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 ON/OFF 5Y 3930mm TB 3000K
	3930	109.2	Textured Black	3000K	ON/OFF	16860	12457
174NF.39O9.930.TW	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 ON/OFF 5Y 3930mm TW 3000K
	3930	109.2	Textured White	3000K	ON/OFF	16860	12457
174NF.39O9.940.AL	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 ON/OFF 5Y 3930mm AL 4000K
	3930	109.2	Anodized aluminium	4000K	ON/OFF	17660	13048
174NF.39O9.940.TB	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 ON/OFF 5Y 3930mm TB 4000K
	3930	109.2	Textured Black	4000K	ON/OFF	17660	13048
174NF.39O9.940.TW	Oris 50mm opal recessed 109,2W CRI>90 90º IP40 ON/OFF 5Y 3930mm TW 4000K
	3930	109.2	Textured White	4000K	ON/OFF	17660	13048
174NF.44O9.930.AL	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 ON/OFF 5Y 4490mm AL 3000K
	4490	124.8	Anodized aluminium	3000K	ON/OFF	19270	14193
174NF.44O9.930.TB	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 ON/OFF 5Y 4490mm TB 3000K
	4490	124.8	Textured Black	3000K	ON/OFF	19270	14193
174NF.44O9.930.TW	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 ON/OFF 5Y 4490mm TW 3000K
	4490	124.8	Textured White	3000K	ON/OFF	19270	14193
174NF.44O9.940.AL	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 ON/OFF 5Y 4490mm AL 4000K
	4490	124.8	Anodized aluminium	4000K	ON/OFF	20180	14863
174NF.44O9.940.TB	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 ON/OFF 5Y 4490mm TB 4000K
	4490	124.8	Textured Black	4000K	ON/OFF	20180	14863
174NF.44O9.940.TW	Oris 50mm opal recessed 124,8W CRI>90 90º IP40 ON/OFF 5Y 4490mm TW 4000K
	4490	124.8	Textured White	4000K	ON/OFF	20180	14863
174NF.50O9.930.AL	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 ON/OFF 5Y 5050mm AL 3000K
	5050	140.4	Anodized aluminium	3000K	ON/OFF	21690	15903
174NF.50O9.930.TB	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 ON/OFF 5Y 5050mm TB 3000K
	5050	140.4	Textured Black	3000K	ON/OFF	21690	15903
174NF.50O9.930.TW	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 ON/OFF 5Y 5050mm TW 3000K
	5050	140.4	Textured White	3000K	ON/OFF	21690	15903
174NF.50O9.940.AL	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 ON/OFF 5Y 5050mm AL 4000K
	5050	140.4	Anodized aluminium	4000K	ON/OFF	22680	16629
174NF.50O9.940.TB	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 ON/OFF 5Y 5050mm TB 4000K
	5050	140.4	Textured Black	4000K	ON/OFF	22680	16629
174NF.50O9.940.TW	Oris 50mm opal recessed 140,4W CRI>90 90º IP40 ON/OFF 5Y 5050mm TW 4000K
	5050	140.4	Textured White	4000K	ON/OFF	22680	16629
SeeMore...

ACCESSORIES

Joint ON/OFF ORIS 50	Product code
80303071

Joint DALI ORIS 50	Product code
80303073

Casambi - DALI Interface	Product code
Casambi - DALI Interface CASAMBI	8030-2590

Related Projects

URBANFLY

Noticias Relacionadas

HAVE YOU SEEN OUR ORIS COLLECTION?
