Ross Magnetic track light 48V

Ross Magnetic 48V
79 80 91
Request a Lighting Project

This track light was designed to provide high luminous performance into a small product. With only 55mm diameter, it integrates a heatsink of high thermal conductivity. This track light is ideal for projects where high levels of quality light are necessary, highlighting products or special spaces. The ROSS has been specially designed to be used with an adapter in low voltage magnetic rails but it is also available with inTrack driver version for universal 3 circuit rail of 230V. Recently, two new solutions for the use of this lighting fixture has been added: Surface and recessed.



Note: The Ross with code 401/412/474 is compatible with BT1/TK3 rails (Short Holder) while the Ross with code 407/414/476 is compatible with BT2/TK5/TK9 rails (Long Holder).

MOUNTING TYPE    Magnetic
LIGHT DISTRIBUTION    Direct
POWER SUPPLY    48V / TRACK
WARRANTY    5 Years
FINISHING    Textured Black, Textured White
CONTROL    CASAMBI, DALI, ON/OFF



LED FEATURES
LUMINOUS EFFICIENCY  UP TO 133 lm/W
CRI  CRI>90, CRI>97
LIFESPAN  50.000 Hours
STEPS MACADAM  3 Steps MacAdam
LUMEN MAINTENANCE  L90/B50
PHOTOBIOLOGICAL RISK  RG1
Product code LENGTH POWER FINISHING COLOR TEMP. CONTROL TYPE BEAM ANGLE LED LUMENS LUMINAIRE LM


414CS.36.927.TBRoss 12,1W CRI>90 36º IP40 CASAMBI 5Y TB 2700K for BT2/TK5/TK9 Magnetic Track
 12012.1Textured Black2700KCASAMBI3615241295
414CS.60.927.TBRoss 12,1W CRI>90 60º IP40 CASAMBI 5Y TB 2700K for BT2/TK5/TK9 Magnetic Track
 12012.1Textured Black2700KCASAMBI6015241295
414CS.24.927.TBRoss 12,1W CRI>90 24º IP40 CASAMBI 5Y TB 2700K for BT2/TK5/TK9 Magnetic Track
 12012.1Textured Black2700KCASAMBI2415241295
414CS.12.927.TBRoss 12,1W CRI>90 12º IP40 CASAMBI 5Y TB 2700K for BT2/TK5/TK9 Magnetic Track
 12012.1Textured Black2700KCASAMBI1215241295
412DL.12.927.TBRoss 12,1W CRI>90 12º IP40 DALI 5Y TB 2700K for BT1/TK3 Magnetic Track
 12012.1Textured Black2700KDALI1215241295
412DL.24.927.TBRoss 12,1W CRI>90 24º IP40 DALI 5Y TB 2700K for BT1/TK3 Magnetic Track
 12012.1Textured Black2700KDALI2415241295
412DL.36.927.TBRoss 12,1W CRI>90 36º IP40 DALI 5Y TB 2700K for BT1/TK3 Magnetic Track
 12012.1Textured Black2700KDALI3615241295
414DL.24.927.TBRoss 12,1W CRI>90 24º IP40 DALI 5Y TB 2700K for BT2/TK5/TK9 Magnetic Track
 12012.1Textured Black2700KDALI2415241295
412DL.60.927.TBRoss 12,1W CRI>90 60º IP40 DALI 5Y TB 2700K for BT1/TK3 Magnetic Track
 12012.1Textured Black2700KDALI6015241295
414DL.60.927.TBRoss 12,1W CRI>90 60º IP40 DALI 5Y TB 2700K for BT2/TK5/TK9 Magnetic Track
 12012.1Textured Black2700KDALI6015241295
SeeMore...

BT1 Magnetic Track Product code
Magnetic Track 48V 1M Black 3080-0175.BL
Magnetic Track 48V 1M White 3080-0175.WH
Magnetic Track 48V 2M Black 3080-0176.BL
Magnetic Track 48V 2M White 3080-0176.WH



BT2 Magnetic Track Product code
Magnetic Track 48V 1M Black 3080-0177.BL
Magnetic Track 48V 1M White 3080-0177.WH
Magnetic Track 48V 2M Black 3080-0178.BL
Magnetic Track 48V 2M White 3080-0178.WH



TK3 Magnetic Track Product code
Magnetic Track 48V 1M Black 3080-0205.BL
Magnetic Track 48V 1M White 3080-0205.WH
Magnetic Track 48V 2M Black 3080-0206.BL
Magnetic Track 48V 2M White 3080-0206.WH



TK5 48V Magnetic Track Product code
Magnetic Track 48V 1M Black 3080-0250.BL
Magnetic Track 48V 1M White 3080-0250.WH
Magnetic Track 48V 2M Black 3080-0251.BL
Magnetic Track 48V 2M White 3080-0251.WH



TK9 Magnetic Track Product code
Magnetic Track 48V 1M Black 3080-0211.BL
Magnetic Track 48V 1M White 3080-0211.WH
Magnetic Track 48V 2M Black 3080-0212.BL
Magnetic Track 48V 2M White 3080-0212.WH
